4kw Dc To Ac Inverter Charger , TBB Sine Inverter Charger For Weak Grid
4kw Dc To Ac Inverter Charger , TBB Sine Inverter Charger For Weak Grid
4kw Dc To Ac Inverter Charger , TBB Sine Inverter Charger For Weak Grid
4kw Dc To Ac Inverter Charger , TBB Sine Inverter Charger For Weak Grid
4kw Dc To Ac Inverter Charger , TBB Sine Inverter Charger For Weak Grid
4kw Dc To Ac Inverter Charger , TBB Sine Inverter Charger For Weak Grid
4kw Dc To Ac Inverter Charger , TBB Sine Inverter Charger For Weak Grid
4kw Dc To Ac Inverter Charger , TBB Sine Inverter Charger For Weak Grid
Specifications
Brand Name :
TBB
Model Number :
cs4080s
Certification :
CE,ISO9000
Place of Origin :
China
MOQ :
1piece
Price :
Negotiable
Payment Terms :
T/T
Delivery Time :
3-7 working days, depending
Packaging Details :
Carton box, Honeycomb plate, Plywood crate
AC output :
230VAC/50HZ
Brand :
TBB
Model :
cs4040s
Output Type :
Single
Battery Type :
AGM / GEL / LFP / Flooded
Application :
Power Backup system
Dc input :
48VDC
Capacity :
4KW
Description

dc to ac power inverter charge combi 4kw 48VDC40A 230VAC/50HZ cs4040s


Energier Essential bi-directional inverter can be used in multiple applications.You can use it
to compose power backup system. Or, with a quick setting,you can compose a simple solar
hybrid system either with grid or diesel-generators.

Features,

-Designed for tropical region with working temperature up to 60℃
-Compatible with majority of cheap generators in the market
-Can be applied for power backup and solar hybrid system
-Equalization charging program was available
-TBB premium II multi stage charging algorithm with built in
-Bi directional inverter with pure sine wave output
-Optional CM was available for automatic generator start
-Optional SNMP card for remote internet access
-High performance designed for all kinds of home appliances
-Designed to work with weak grid

Connecting the cable

Please make sure Energier essential bi-directional inverter is turned off before connection. Otherwise, high voltage could be present.

Please double check battery voltage match the model you are going to installed, the wrong battery could destroy equipment and is out of warranty.

Please double confirm the polarity of DC input. Reverse polarity could cause permanent damage on equipment and it is out of warranty.
4kw Dc To Ac Inverter Charger , TBB Sine Inverter Charger For Weak Grid

Specification

Model No.12VdcCS0625LCS1040LCS2080L
24VdcCS0615MCS1020MCS2040MCS3060MCS4080M
48Vdc CS3030SCS4040S
INVERTER
Nominal Voltage12Vdc, 24Vdc, 48Vdc
power 30mins @25℃ (W)6001000200030004000
Cont.power@25℃ (W)6001000180025003600
Cont.power@40℃ (W)6001000150020003000
Cos φ0.9-1
Surge300%
Output voltage【1】230VAC or 110VAC ± 2%230VAC ± 2%
Output frequency50Hz or 60Hz ± 0.1%
Efficiency (MAX.)12Vdc88%
24Vdc88%
48Vdc92%

Bypass
range

UPS mode184VAC-264VAC/92VAC-132VAC184VAC-264VAC
GEN mode160VAC-280VAC/80VAC-140VAC160VAC-280VAC
Crest factor3:1
THD<3%
Zero load power1722273662
Zero load power (power save mode)457915
Output circuit breaker5A10A15A30A30A
Overheat protectionauto disconnect
Overload protectionauto disconnect
shortcut protectionauto disconnect
Charger
Nominal Output Voltage12Vdc, 24Vdc, 48Vdc
Max Output current (A) - adjustable25/1540/2080/4060/3080/40
AC Input rangeUPS mode184VAC - 264VAC/92VAC-132VAC184VAC - 264VAC
GEN mode160VAC - 280VAC/80VAC-140VAC160VAC - 280VAC
Battery typesAGM / GEL / LFP / Flooded
Absorption timevariable
Temperature compensation-4mV/℃/cell
Charger circuit breaker5A10A15A30A30A
Other Data
Transfer timeUPS mode15ms
GEN mode2s
Transfer switch40A
Battery connectorM8 x 2
AC connectorTerminal block (M3 screw)
Mechanical Data
EnclosureSteel with powder paint
Dimension (mm)444x186x135512x216x176
Net Weight (kgs)9.5141618.522.5
CoolingForced fan
ProtectionIP20
Standard
SafetyEN60950-1
EMCEN55022,EN55024
【1】Output voltage: 220VAC/60Hz for Philippines
