100 Watt 12 Volt Polycrystalline Solar Panel Durable 675x540x30mm
100 Watt 12 Volt Polycrystalline Solar Panel Durable 675x540x30mm
100 Watt 12 Volt Polycrystalline Solar Panel Durable 675x540x30mm
100 Watt 12 Volt Polycrystalline Solar Panel Durable 675x540x30mm
100 Watt 12 Volt Polycrystalline Solar Panel Durable 675x540x30mm
100 Watt 12 Volt Polycrystalline Solar Panel Durable 675x540x30mm
100 Watt 12 Volt Polycrystalline Solar Panel Durable 675x540x30mm
100 Watt 12 Volt Polycrystalline Solar Panel Durable 675x540x30mm
Specifications
Brand Name :
SolarverTech
Model Number :
SLW-PL100W
Certification :
CE, ISO, TUV, Rohs
Place of Origin :
Jiaxing,Zhejiang,China
MOQ :
1 pcs
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
500000 Watt/Watts per Week cheap pv module
Delivery Time :
1-10 pcs 7 days , 11- 100 pcs 15days ; 101-300 pcs 25 days
Packaging Details :
Normally packing: 1pc/2pcs/3pcs/10pcs/25pcs per carton; Individual packing requirement is acceptable.
Product name :
poly solar panel 50w
Panel Dimensions :
675*540*30mm
Frame :
Aluminium alloy
Open circuit voItage (Voc) :
21.41
Maximum Power voItage (Vm) :
17.02
Maximum Power current (Im) :
2.94
Description

100 Watt 12 Volt Polycrystalline Solar Panel Durable 675x540x30mm

Parameter:

Technical Parameter

Rated Output

(Wp)

Opencircuit voItage

(Voc)

Maximum Power voItage

(Vm)

Short circuit current

(Isc)

Maximum Power current

(Im)
50 21.41 17.02 3.49 2.94
Temperature Coefficient of Voc -0.38%/℃ CeII(mm) 156*52
Temperature Coefficient of lsc +0.04%/℃ Weight(kg)
Temperature Coefficient of Power -0.47%/℃ Dimensions(LxWxH)(mm) 675*540*30
NOCT 45±3℃

Cable Cross Section Size

(mm)

 2*1.5
Working Temperature Range - 40℃~+85℃ No.of Cells and Connections 36(4*9)
Maximum Permitted Load 5400Pa No.of Diodes 1*10A
Maximum Series Fuse Rating(A) 10 Monolithic power 3.5 w-4.29 w
Maximum System Voltage(V) 1000 The efficiency of single chip 14.38%-17.6%
Standard Test Conditions 1000W/m2;25℃;AM1.5 The packing way 5pcs/Carton

100 Watt 12 Volt Polycrystalline Solar Panel Durable 675x540x30mm

100 Watt 12 Volt Polycrystalline Solar Panel Durable 675x540x30mm

100 Watt 12 Volt Polycrystalline Solar Panel Durable 675x540x30mm

Payment Terms

1. Payment: T/T, Western Union, MoneyGram,PayPal; 30% deposits; 70% balance before delivery.

2. MOQ: 1pcs.

3. Warranty : 10 years/25 years .

4. Package Informations: please contact us to ensure it. coz different item has different dimension .
