2400W Off Grid 3KVA Solar Inverter With MPPT Multiscene Durable
2400W Off Grid 3KVA Solar Inverter With MPPT Multiscene Durable
2400W Off Grid 3KVA Solar Inverter With MPPT Multiscene Durable
2400W Off Grid 3KVA Solar Inverter With MPPT Multiscene Durable
2400W Off Grid 3KVA Solar Inverter With MPPT Multiscene Durable
2400W Off Grid 3KVA Solar Inverter With MPPT Multiscene Durable
Specifications
Brand Name :
SolarverTech
Model Number :
MPS3K-24
Place of Origin :
Zhejiang, China
MOQ :
100
Price :
negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Supply Ability :
200000
Delivery Time :
samples in 5 working day
Packaging Details :
as requirement
Product name :
3kva/2.4kw 2400w solar inverter with MPPT solar charge controller
Type :
off grid
Inverter Efficiency :
95%
warranty :
12 months
OEM :
accept
Application :
Home solar system
Output Current: :
25-60A
Description

3kva/2.4kw 2400w solar inverter with MPPT solar charge controller

Product Description

Pure sine wave inverter

Built-in MPPT solar charge controller

selectable input voltage range for home appliances and personal computers

Selectable charging current based on applications

Configurable AC/Solar input priority via LCD setting

Compatible to mains voltage or generator power

Auto restart while AC is recovering

Overload and short circuit protection

Smart battery charger design for optimized battery performance

parallel operation with up to 6 units (30KVA) only

Available for 5KVA

2400W Off Grid 3KVA Solar Inverter With MPPT Multiscene Durable

Specification

MODELMPS 1K-24MPS 3K-24MPS 5K-48
Rated Power1000VA/800W3000VA/2400W5000VA/4000W
INPUT
Voltage230VAC
Selectable Voltage Range170-280VAC (for personal computers)
90-280VAC (for home appliances)
Frequency Range50Hz/60Hz (Autosensing)
OUTPUT
AC Voltage Regulation (Batt. Mode)230VAC±5%
Surge power2000VA6000VA10000VA
Efficiency (Peak)90-93%93%93%
Transfer Time10ms (for personal computers)
20ms (for home appliances)
Wave formPure Sine Wave
BATTERY & ACCHARGER
Battery Voltage24VDC24VDC48VDC
Floating Charge Voltage27VDC27VDC54VDC
Overcharge Protection31VDC31VDC60VDC
Maximum charge current10A/20A20A/30A10A/20A/30A/40A/50A/60A
SOLAR CHARGER
MAX. PV Array Power1000W1000W1500W3000W/4000W
MPPT Range@ Operating Voltage30-66VDC30-66VDC30-115VDC60-115VDC
Maximum PV Array Open Circuit Voltage75VDC75VDC145VDC145VDC
Maximum Charging Current40A40A60A60A/80A
Maximum Efficiency98%
Standby Power Consumption2W
PHYSICAL
Dimension. D*W*H(mm)368*272*128367.6*272439*296*141468*295*136
Net Weight (kgs)7.4kg8.0kg10kg9.8kg
OPERATING ENVIRONMENT
Humidity5% to9 5% Relative Humidity (Non-condensing)
Operating Temperature0℃ to 55℃
Storage Temperature-15℃ to 60℃

Application

2400W Off Grid 3KVA Solar Inverter With MPPT Multiscene Durable

Company Profile

We are professional off-grid power inverter supplier,
is a sino-german joint venture, mainly engaged in off-grid power inverter/MPPT and PWM controller, research and development, manufacturing and sales,
we can provide customers with off-grid power inverter & converter OEM and ODM.

We Solarway New Energy company will launch 4-5 new products every year and leading the market .
