Coaxial 4 Pin Connector TGG ZGG 2B Push Pull Aviation Plug Panel Fixed Socket
Coaxial 4 Pin Connector TGG ZGG 2B Push Pull Aviation Plug Panel Fixed Socket
Coaxial 4 Pin Connector TGG ZGG 2B Push Pull Aviation Plug Panel Fixed Socket
Coaxial 4 Pin Connector TGG ZGG 2B Push Pull Aviation Plug Panel Fixed Socket
Coaxial 4 Pin Connector TGG ZGG 2B Push Pull Aviation Plug Panel Fixed Socket
Coaxial 4 Pin Connector TGG ZGG 2B Push Pull Aviation Plug Panel Fixed Socket
Specifications
Brand Name :
Sreada
Model Number :
SRD.ZGG.2B.704.CLL
Place of Origin :
Guangdong, China
MOQ :
50 Sets
Price :
$3.00 - $30.00/Sets
Payment Terms :
L/C, D/P, T/T
Supply Ability :
5000 Set/Sets per Week
Delivery Time :
5-7 Days
Packaging Details :
by packaged vaccum seal bags or plastic boxes,then carton packaging
Cores :
4
Series :
2B
Temperature :
-45℃~+125℃
Vibration :
10-20000HZ,15g
Mechanical shock :
100g.6ms
Protection level :
IP50
Contact material :
copper gold plating
Insert material :
PPS
Description

Compatible with Connector TGG ZGG 2B 4-core 1 Coaxial push-pull self-locking Aviation Plug Panel Fixed socket

Quick detail of ZGG.2B.704 connectors:

1. Security of the push-pull self-latching system

2. Multicore types with 2 to 32 pins

3. Solder or PCB contacts available

4. High-density installation for space-saving

5. Multiple key options to avoid cross mating or similar connectors

6. Robust and shock resistant designs ideal for equipment used in the field

Coaxial 4 Pin Connector TGG ZGG 2B Push Pull Aviation Plug Panel Fixed Socket

Specifications of ZGG.2B.704 connectors:

Endurance >5000 cycles
Humidity Maximum humidity up to 95% at a temperature of 60℃
Temperature -45℃~+125℃
Vibration 10~20000HZ,15g
Mechanical shock 100g.6ms
Salt spray corrosion test >48hrs
Protection level IP50
Termination Solder
Fastening type Push-pull
Shell finish Chrome
Shell color Silver
Contact material Brass
Contact color Gold
Insert material PPS

Applications of ZGG.2B.704 self-locking connectors:

1. medical: diagnostic devices, surgical instrumentation, therapy applications, medical imaging

2. broadcast: HD and SD cameras, remote camero control, studios and outside broadcasting, TV and motion picture

3. extreme: motorsports, sailboat racing, diving, submarine industry, weatherproof applications

4. energy: petrol&gas, nuclear, renewable energies, batteries, fuel cells

5. defense&security: surveillance equipment, computers, target acquisition, communication systems

Coaxial 4 Pin Connector TGG ZGG 2B Push Pull Aviation Plug Panel Fixed Socket

About us:
Precision manufacturing is Sreada's core competence.
As a highly vertically integrated corporation,Sreada also controls the vast majority of its manufacturing process from procuring raw materials, through tool making to production, plating, final assembly, and testing.
Total control over these process allow Sreada to react much more quickly to special or high volume customers needs. Each of the manufacturing sites specializes in its own discipline-turning of large volume products, low volume special products, plastic parts, plating, and assembly.
The continuous and rigorous application of strict quality standards guarantees the consistent production of high quality connectors that exceed customers’ expectations year-after-year.
