1.5mm2 Bared Copper Wires And Cables Standard Pure Annealed Copper Conductor
1.5mm2 Bared Copper Wires And Cables Standard Pure Annealed Copper Conductor
1.5mm2 Bared Copper Wires And Cables Standard Pure Annealed Copper Conductor
1.5mm2 Bared Copper Wires And Cables Standard Pure Annealed Copper Conductor
1.5mm2 Bared Copper Wires And Cables Standard Pure Annealed Copper Conductor
1.5mm2 Bared Copper Wires And Cables Standard Pure Annealed Copper Conductor
Specifications
Brand Name :
YANGDA
Model Number :
RV
Certification :
ISO9001,UL,VDE certificate
Place of Origin :
CHINA
MOQ :
3050M
Price :
0.105 USD PER METER
Payment Terms :
T/T
Supply Ability :
1000000 PER WEEK
Delivery Time :
10DAYS
Packaging Details :
CARTON
Conductor type :
Stranded
Conductor material :
Copper,tinned or bare copper
Application :
Heating,Overhead,For indoor small electrical instruments,Housing project or Building
Type :
Insulated
Insulation material :
PVC
Color :
Various color available,blue,grey,yellow,customized
Product name :
copper flexible insulated pvc cable wire electrical,electrical cable solid copper 7 core PVC wire with lowr price,UL1015 Hook-up wire cable,UL1185 1.5mm2
Conductor :
Tinned or Bare,stranded or solid copper,copepr,Copper Core
Rated voltage :
600V,300/500V 450/750V
Voltage :
low medium voltage
Insulation :
PVC,PVC Insulation Cable
Description

Iso Pvc Jacket Wire Factory Ccc Certificate Rv 1.5mm2 Bared Copper Electrical Wire

Product description

- Rated temperature : 70°C

- Rated voltage : 300/500V

- Conductor: Solid or standard pure annealed copper

- Insulation: PVC material

Technical Data:

* Insulation:RV

* Nominal Voltage:300V/500V(RV-06 & RV-90);450V/750V(RV-02)

* Temperature Range:-30℃~+70℃

* Conductor:Bare or tinned copper strand

* Standard:60227IEC,GB/T 5023.3-2008

* RoHS

Model Size(mm²) Conductor(mm)
RV-02 1.50 30/0.25
2.50 50/0.25
4.00 56/0.30
6.00 84/0.30
10.00 80/.040
RV-06 0.50 16/0.20
0.75 24/0.20
1.00 32/0.20
RV-90 0.50 16/0.20
0.75 24/0.20
30/0.18
1.00 32/0.20
1.50 30/0.25
2.50 50/0.25

Nominal section No./dia. of core Average dia.(mm) Reference weight Conductor resistance at 20℃
(mm2) (mm) min max (kg/km) (Ω/km)
0.5 16/0.2 2.1 2.5 9.1 26
0.75 24/0.2 2.2 2.7 12.2 19.5
1.0 32/0.2 2.4 2.8 15.1 13.3

Nominal section No./dia. of core Average dia.(mm) Reference weight Conductor resistance at 20℃
(mm2) (mm) min max (kg/km) (Ω/km)
1.5 30/0.25 2.8 3.4 21.5 13.3
2.5 49/0.25 3.4 4.1 24.5 7.98
4 56/0.30 3.9 4.8 51.8 4.05
6 84/0.30 4.4 5.3 74.7 3.30
10 84/0.40 5.7 6.8 124 1.91
16 134/0.40 6.7 8.1 188 1.21
25 210/0.40 8.4 10.2 295 0.780
35 294/0.40 9.7 11.7 400 0.554
50 420/0.40 11.5 13.9 547 0.386
70 356/0.50 13.2 16.0 771 0.272
95 484/0.50 15.1 18.2 1010 0.206
120 612/0.50 16.7 20.2 1239 0.161
150 765/0.50 18.6 22.5 1544 0.129
185 942/0.50 20.6 24.9 1900 0.106
240 1224/0.50 23.5 28.4 2478 0.0801
