PU Jacket Spiral Electrical Wire , Copper Spiral Power Cable Flame Resistant
PU Jacket Spiral Electrical Wire , Copper Spiral Power Cable Flame Resistant
PU Jacket Spiral Electrical Wire , Copper Spiral Power Cable Flame Resistant
PU Jacket Spiral Electrical Wire , Copper Spiral Power Cable Flame Resistant
PU Jacket Spiral Electrical Wire , Copper Spiral Power Cable Flame Resistant
PU Jacket Spiral Electrical Wire , Copper Spiral Power Cable Flame Resistant
Specifications
Brand Name :
YANGDA
Model Number :
customized
Certification :
UL
Place of Origin :
YANGDA
MOQ :
10000m
Price :
1usd per meter
Payment Terms :
T/T
Supply Ability :
1000000 per week
Delivery Time :
10days
Packaging Details :
rolls in carton
Material :
TPU
Standard :
UL758
Flame :
vw-1
rating voltage :
600V/1000V
Aplication :
Electrical equipment
Description

PU Jacket Flame Retartent Copper Wire Customized Multi-Cores Robot Pu Machinery Power Wire Elastic Pu Spiral Cable
sprial coiled cable,electric wire,Computer wire,apring cable,flexible cable,PUR Cable

Product Description:
1) Tinned , annealed, stranded or solid copper conductor.
2) PVC/SR-PVC/PP/TPU/XL-PE insulation.
3) TPU jacketed.
4) Rated temperature: 60°C. Rated voltage: 600/1000Volts.
5) Uniform thickness of wire to ensure easy stripping and cutting.
6) Passes UL VW-1 & CSA FT1 vertical flame test.
7) Tinned or bare copper winding isolation.
8) A collection of cores can be isolated tissue-paper package aluminum foil or mylar.
9) Executive Standard: UL758, UL1581, CSA22.2.
Applications:
1) For general purpose internal wiring of electronic and electrical equipment.

Conductor: multi-strands copper or tinned copper
Cores: 6/7/12/14/15/16/18/19/20/26 cores or as your demand
Cross section:0.12-- 4 mm² or as your customized
Insulation material: PVC/PE/PP
Jacket material: PU/TPU/PP/PVC/TPE
Length:5M,10M,20M or as your request
Operating temperature: according to customer requirements, cold -65 degrees; temperature 80 degrees, 105 degrees, 125 degrees
Advantage:Good flexibility and elasticity
Elongation length of up to 3.5-4 times the original length of spring. Have good cold resistance, flame resistance, oil and abrasion resistance.

Occasions:according to different requirements of production of various kinds of spiral-type spring line.
Rated temperture: -40℃~80℃

Conductor material
Fine copper wire stranded
Core insulation
PU,PVC avilable
Color
to be customized
Cable Length
to be customized
Quality
100% tested
MOQ
100pcs
Sample availablity
Free sample 1~2pcs can be offered
Applications
Industrial Machinery, Robots etc.

Material All materials are ROHS certified
length of lanyard nature length can be 80-120cm or as requirement
Connectors Micro usb, Power Plug,Hirose,JST,Molex,AMP,Deutsch,etc
coating PVC,PU,PE,nylon,etc

Length		 Customized or according to your requirements
Lanyard color Black or as requirements
Service OEM ODM products are welcomed. We accept customization according to your requirements.
Delivery Time Strong production capacity ensure delivery time.
Packaging 100/200/300/500pcs per bag with label, then outside carton
