Pvc Flexible Cable Ul3785 Single Core Xl-Pvc Insulation Tinned Copper Wire For Electric Vehicle Charging
Pvc Flexible Cable Ul3785 Single Core Xl-Pvc Insulation Tinned Copper Wire For Electric Vehicle Charging
Pvc Flexible Cable Ul3785 Single Core Xl-Pvc Insulation Tinned Copper Wire For Electric Vehicle Charging
Pvc Flexible Cable Ul3785 Single Core Xl-Pvc Insulation Tinned Copper Wire For Electric Vehicle Charging
Pvc Flexible Cable Ul3785 Single Core Xl-Pvc Insulation Tinned Copper Wire For Electric Vehicle Charging
Pvc Flexible Cable Ul3785 Single Core Xl-Pvc Insulation Tinned Copper Wire For Electric Vehicle Charging
Specifications
Brand Name :
YANGDA
Model Number :
3785
Certification :
ISO9001,UL,VDE certificate
Place of Origin :
CHINA
MOQ :
3050M
Price :
0.13USD PER METER
Payment Terms :
T/T
Supply Ability :
1000000 PER WEEK
Delivery Time :
10DAYS
Packaging Details :
CARTON
Conductor type :
Stranded
Conductor material :
Copper,tinned or bare copper
Application :
Heating,Overhead,For indoor small electrical instruments,Housing project or Building
Type :
Insulated
Insulation material :
PVC
Color :
Various color available,blue,grey,yellow,customized
Product name :
copper flexible insulated pvc cable wire electrical,electrical cable solid copper 7 core PVC wire with lowr price,UL1015 Hook-up wire cable,UL1185 1.5mm2
Conductor :
Tinned or Bare,stranded or solid copper,copepr,Copper Core
Rated voltage :
600V,300/500V 450/750V
Voltage :
low medium voltage
Insulation :
PVC,PVC Insulation Cable
Description

Pvc Flexible Cable Ul3785 Single Core Xl-Pvc Insulation Tinned Copper Wire For Electric Vehicle Charging

Product Description:

1) Tinned, annealed, stranded or solid copper conductor.

2) XL-PVC insulation.

3) Rated temperature: 90°C. Rated voltage: 150volts.

4) Uniform thickness of wire to ensure easy stripping and cutting.

5) Passes UL VW-1 & CSA FT1 vertical flame test.

6) Top coated conductor is avaiable.

Applications:

- For general purpose internal wiring of electronic and electrical equipment.

UL Style& CSA Type Conductor Insulation
Thickness		 Overall
Diameter		 Standard Put-up Conductor
Resistance at 20℃
AWG No/mm mm mm Ft/coil M/Coil Ω/KM
UL3785
CSA
(Stranded)		 26 7/0.16 0.25 1.00 2000 610 150.00
24 11/0.16 0.25 1.10 2000 610 94.20
22 17/0.16 0.25 1.30 2000 610 59.40
20 21/0.178 0.25 1.50 2000 610 36.70
18 34/0.178 0.25 1.80 2000 610 23.20
16 26/0.25 0.25 2.10 2000 610 14.60

Pvc Flexible Cable Ul3785 Single Core Xl-Pvc Insulation Tinned Copper Wire For Electric Vehicle Charging


Pvc Flexible Cable Ul3785 Single Core Xl-Pvc Insulation Tinned Copper Wire For Electric Vehicle Charging
