305mm 12 Inch Discharge PVC Layflat Hose / Lay Flat Plastic Tubing With Low Expansion
305mm 12 Inch Discharge PVC Layflat Hose / Lay Flat Plastic Tubing With Low Expansion
305mm 12 Inch Discharge PVC Layflat Hose / Lay Flat Plastic Tubing With Low Expansion
305mm 12 Inch Discharge PVC Layflat Hose / Lay Flat Plastic Tubing With Low Expansion
Specifications
Brand Name :
ET
Model Number :
1''-16''
Certification :
ISO9001:2008;SGS
Place of Origin :
Shandong, China (Mainland)
MOQ :
1000m
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
4000tons / per year
Delivery Time :
10-15 work days
Packaging Details :
woven plastic cloth wrapped, covered by paper card
name :
12 inch discharge hose
inner diameter :
305mm
wall thickness :
2.4mm
working pressure :
2bar
sample :
available
usage :
water discharge
Description

305mm 12 Inch Discharge PVC Layflat Hose / Lay Flat Plastic Tubing With Low Expansion

product 12 lay flat discharge hose
Color blue, green, yellow, red, black, orange, gray etc
temperature range -5℃ to 65℃
length 50m, 100m or customized
features

low expansion
application

delivery clean water, trash water, mild chemicals, industry waste water etc

Feature:

Superior abrasion resistance

Extremely hard wearing and durable for long service life

Ultra-high tensile strength

Resistance to oil, fuel and a wide range of chemicals

Resistance to weathering, UV and ozone

Lightweight and easy to handle compared to material handling hose in rubber

Available in different colors

Application:

Agriculture and mining, Transport of abrasive materials, Flexible pipeline even in extreme terrain Irrigation and sludge disposal, Supply hose for liquid manure and sludge injection systems, for heavy duty service under toughest conditions, Recommended for Manure Transfer Solutions.

Packaging:

Plastic film, woven bags and any other forms as per customers' requests

Specification:

Standard Duty PVC Layflat Hose

Inner Diameter Wall Thickness Weight W.P.(at 23℃) Std Length
inch mm inch mm kg/m bar psi m ft
1 25 0.047 1.20 0.15 5 75 100 300
1-1/4 32 0.047 1.20 0.17 5 75 100 300
1-1/2 38 0.049 1.25 0.19 5 75 100 300
2 51 0.043 1.10 0.22 4 60 100 300
2-1/2 64 0.047 1.20 0.30 4 60 100 300
3 76 0.047 1.20 0.35 4 60 100 300
4 102 0.047 1.20 0.53 4 60 100 300
5 127 0.053 1.35 0.75 4 60 100 300
6 153 0.053 1.35 0.90 4 60 100 300
8 203 0.071 1.80 1.60 3 45 100 300
10 254 0.094 2.40 2.60 3 45 50 150
12 305 0.094 2.40 3.10 2 30 50 150
14 358 0.118 3.00 5.00 2 30 50 150
16 408 0.118 3.00 6.00 2 30 50 150
