Flange Joint Wire Reinforced Rubber Hose / Corrugated Suction Hose ISO 9001 Approved
Flange Joint Wire Reinforced Rubber Hose / Corrugated Suction Hose ISO 9001 Approved
Flange Joint Wire Reinforced Rubber Hose / Corrugated Suction Hose ISO 9001 Approved
Flange Joint Wire Reinforced Rubber Hose / Corrugated Suction Hose ISO 9001 Approved
Flange Joint Wire Reinforced Rubber Hose / Corrugated Suction Hose ISO 9001 Approved
Flange Joint Wire Reinforced Rubber Hose / Corrugated Suction Hose ISO 9001 Approved
Specifications
Brand Name :
ET
Model Number :
1''-10''
Certification :
ISO9001
Place of Origin :
Shandong, China
MOQ :
1000m
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
100000m / per month
Delivery Time :
15-20 work days
Packaging Details :
woven bag in roll, or according customers required for suction hose
name :
flexible rubber hose
material :
rubber
inner diameter :
25.4mm to 254mm
sample :
available
working pressure :
10kg/cm²
weight :
0.89kg/m to 21.98kg/m
Description

flange joint wire reinforced pump corrugated water suction and discharge hose / pipe

specification 1inch to 10inch
color black, yellow or customized
length 20m, 30m, 60m/roll or as consumer's requst
bending radius 6inch to 100inch
features flexible ,durable, weather and abrasion resistant.
application

water pumping in mining, agricultural irrigation, construction work

Application:

High quality fiber braided rubber water suction hose for medium to heavy-duty applications, used in the discharge of fluids from industry.

Suctioning and transporting water or other neutral fluids at room temperature.

It can be used as input pipe or output pipe for water pumping in mining, agricultural irrigation, construction work or other industrial fields.

Construction:

Tube: NR/SBR synthetic rubber, black conductive NR-Abrasion Resistant

Cover: Black synthetic rubber, wrapped spiral embossed lay line. Black conductive SBR/NR-abrasion and ozone resistant.

Reinforcement: spiral plied fabrics and spiral steel wire.

Temperature Range: -20℃to 80℃

Packing: Plastic inner side and woven outer side, Color packing or customized.

Our Services

1. We can design the perfect hose suit to your application.

2. Our quality are reliable and price is reasonable.

3. Good service in order and after sale.

4. Receive small order.

5. Factory equipped with Italy VP automatic production lines.


Specification:

ID Ply OD Length Bending radius WP VP Weight
in mm Ply in mm Ft M in mm Psi Kg/cm² mm-Hg Kg/m
1 25.4 2 1.437 36.5 200 60 6 150 150 10 736.6 0.89
1-1/4 31.8 2 1.689 42.9 200 60 8 200 150 10 736.6 1.04
1-1/2 38.1 2 1.937 49.2 200 60 10 250 150 10 736.6 1.21
2 50.8 2 2.457 62.4 200 60 12 300 150 10 736.6 1.69
2-1/2 63.5 2 2.957 75.1 200 60 15 375 150 10 736.6 2.04
3 76.2 2 3.496 88.8 200 60 20 500 150 10 736.6 2.80
4 101.6 2 4.587 116.5 200 60 28 700 150 10 736.6 4.67
5 127.0 4 5.752 146.1 200 60 40 1000 150 10 736.6 6.45
6 152.4 4 6.752 171.5 200 60 48 1200 150 10 736.6 7.63
8 203.2 4 8.854 224.9 100 30 64 1600 150 10 736.6 13.01
10 254.0 6 11.11 282.2 65 20 100 2500 150 10 736.6 21.98
