High Intensity PVC Fiber Hose , Steel Wire Composite Hose Pipe Anti Abrasion
High Intensity PVC Fiber Hose , Steel Wire Composite Hose Pipe Anti Abrasion
High Intensity PVC Fiber Hose , Steel Wire Composite Hose Pipe Anti Abrasion
High Intensity PVC Fiber Hose , Steel Wire Composite Hose Pipe Anti Abrasion
High Intensity PVC Fiber Hose , Steel Wire Composite Hose Pipe Anti Abrasion
High Intensity PVC Fiber Hose , Steel Wire Composite Hose Pipe Anti Abrasion
Specifications
Brand Name :
ET
Model Number :
1"-4''
Certification :
ISO9001:2008,SGS,ROHS
Place of Origin :
Shandong, China
MOQ :
1000m
Price :
$0.03-$5 / meter
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
6000tons / year
Delivery Time :
10-15 work days
Packaging Details :
transparent plastic film wrapped
product name :
PVC reinforced hose
standard :
ISO; SGS etc.
material :
pvc ,steel wire, polyester fiber
inner diameter :
25mm-100mm
outer diameter :
33mm-116mm
thickness :
4mm-8mm
Description

pvc high-intensity polyester fiber and steel wire composite reinforced hose / pipe

Description:

This hose, made with steel wire screwing inlaid in the hose, and high quality fiber reinforcement by advanced technology, can keep its shape and work normally under higher pressure as well as minus pressure conditions, which is much stronger and durable than normal steel wire reinforced hose. By adding colorful symbol lines on the surface of the hose, it looks more beautiful.

specification 1inch-4inch
color blue, transparent, green etc.
length 20m, 30m, 50m/roll or as consumer's requst
working pressure 4bar to 8bar
burst pressure 12bar to 24bar
application conveying air, liquid, powder etc.

Construction:

pvc outer layer

pvc inner layer

spiral zinc-plated steel wire

polyester fiber reinforcement.

Application:

The hose is suitable for drawing and conveying liquid, gas and powder under high working pressure in factories, agriculture, engineering, foodstuffs and sanitation lines.

Specification:

Inner Diameter Outer Diameter Weight W.P.(at 23℃) Std Length
inch mm inch mm kg/m bar psi m ft
1 25 1.299 33 0.54 8 120 50 150
1-1/4 32 1.614 41 0.78 8 120 40 120
1-1/2 38 1.889 47 1.05 7 105 40 120
2 50 2.441 61 1.60 7 105 40 120
2-1/2 64 3.149 78 2.80 7 105 30 90
3 75 3.582 90 3.50 6 90 30 90
3-1/2 90 4.251 106 4.50 5 75 20 60
4 100 4.645 116 4.80 4 60 20 60
