Plastic Suction Hose , Heavy Duty PVC Fabric Reinforced Hose Oil Resistant reinforced
Plastic Suction Hose , Heavy Duty PVC Fabric Reinforced Hose Oil Resistant reinforced
Plastic Suction Hose , Heavy Duty PVC Fabric Reinforced Hose Oil Resistant reinforced
Plastic Suction Hose , Heavy Duty PVC Fabric Reinforced Hose Oil Resistant reinforced
Plastic Suction Hose , Heavy Duty PVC Fabric Reinforced Hose Oil Resistant reinforced
Plastic Suction Hose , Heavy Duty PVC Fabric Reinforced Hose Oil Resistant reinforced
Specifications
Brand Name :
ET
Model Number :
2"-8''
Certification :
ISO9001:2008,SGS,ROHS
Place of Origin :
Shandong, China
MOQ :
1000m
Price :
$0.03-$5 / meter
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
6000tons / year
Delivery Time :
10-15 work days
Packaging Details :
transparent plastic film wrapped
product name :
suction and discharge hose
material :
pvc and fabric
working temperature :
-5℃-65℃
inner diameter :
50mm-201mm
sample :
available
oem/odm :
available
Description

plastic pvc fabric reinforced suction and discharge hose / pipe with oil resistant

Product description:

heavy duty PVC fabric reinforced suction and discharge hose. Fabric reinforcement - designed with high tensile strength polyester yarn jacket to handle both suction and higher pressure discharge applications.

Transparent hoses allow the user visual confirmation of material flow, and the ability to see if material or condensation has collected in the hose tube. Rigid helix design protects hose tube from cover wear, allows hose to slide easily over rough surfaces. Easy-to-handle.

specification 2'', 2-1/2'', 3'', 4'', 6'', 8''
color yellow, blue, gray, red, orange, black etc.
length 10m, 30m,50m/roll or as consumer's requst
bending radius 0.5m-1.9m
features flexible, transparent, light weight, oil resistant
application fish suction, irrigation lines, pumps

Features:

suction and discharge hose, reinforced with spiral pvc and fabric

Easy slide - hoses with an external rigid helix designed to slide easily over rough surfaces, easy-to-handle

Transparent construction allows for visual confirmation of material flow

Hoses can be used for freshwater and saltwater transfer

Service temperature: -5℃ to 65℃

General applications:

fish suction, irrigation lines, pumps, rental and construction dewatering, pumps, trash, suction and discharge, water suction - heavy duty.

Construction:

double-ply PVC tube, polyester fabric reinforcement and rigid PVC helix.

Specifications:

Inch I.D. O.D.

LENGTH

/COIL

 NEGATIVE PRESSURE B.P BENDING RADIUS WEIGHT
mm mm m MPa MPa m kg/m
2 50±1 62 50 0.097 1.9 0.5 1.1
2-1/2 64±1 77 30 0.097 1.5 0.6 1.5
3 75±1 90 30 0.097 1.2 0.65 1.8
4 102±1.5 119 30 0.097 0.9 0.85 2.7
6 152±1.5 174 11 0.097 0.7 1.5 5.7
8 201±1.5 224 11 0.097 0.5 1.9 8.0
