Heavy Duty Discharge Hose / PVC Water Suction Hose Abrasion Resistant
Heavy Duty Discharge Hose / PVC Water Suction Hose Abrasion Resistant
Heavy Duty Discharge Hose / PVC Water Suction Hose Abrasion Resistant
Heavy Duty Discharge Hose / PVC Water Suction Hose Abrasion Resistant
Heavy Duty Discharge Hose / PVC Water Suction Hose Abrasion Resistant
Heavy Duty Discharge Hose / PVC Water Suction Hose Abrasion Resistant
Specifications
Brand Name :
ET
Model Number :
3/4"-8''
Certification :
ISO9001:2008,SGS,ROHS
Place of Origin :
Shandong, China
MOQ :
1000m
Price :
$0.03-$5 / meter
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
6000tons / year
Delivery Time :
10-15 work days
Packaging Details :
transparent plastic film wrapped
product name :
heavy duty pvc suction hose
size :
19mm-203mm
material :
pvc and rigid pvc
standard :
SGS; ISO
weight :
0.28-7kg/m
thickness :
3mm-8mm
Description

heavy duty pvc spiral water suction and discharge hose / pipe with wear resist

type corrugated type and flat type
color yellow, blue, gray, red, orange, black etc.
length 10m, 20m, 30m, 50m/roll or as consumer's requst
working pressure 45psi to 120psi
features light weight, good elasticity, weather resistance
application conveying powder, grain, water and oil, etc

Application:

As suction and discharge hose very ideally for abrasive mineral sands, gravel, cement, powders, chips, shavings;

Suitable for conveying powder, grain, water and oil, etc. in the industry, agriculture, irrigation and civil engineering. It is the ideal alternative of rubber hose and metal pipe.

Feature:

This product adopts special materials and processing, low temperature resistance, light weight, good elasticity, negative pressure resistance, weather resistance, the product can maintain good performance at hard condition.

1. Extremely abrasive resistant
2. Extremely anti crush
3. Inside surface perfectly smooth, outside corrugated or smooth
4. Could be manufactured anti-static upon request
5. High tensile strength and tear resistant
6. Good resistance to oil and fuel
7. Good resistance to UV and ozone
8. Could be resistant to chemicals

Specification:

Inner Diameter Outer Diameter Weight W.P.(at 23℃) Std Length
inch mm inch mm kg/m bar psi m ft
3/4 19 0.984 25 0.28 8 120 50 150
1 25 1.260 32 0.38 8 120 50 150
1-1/4 32 1.535 39 0.45 7 100 50 150
1-1/2 38 1.850 47 0.70 7 100 50 150
2 51 2.402 61 1.10 6 90 50 150
2-1/2 64 2.913 74 1.30 6 90 30 90
3 76 3.386 86 1.70 5 75 30 90
4 102 4.567 116 3.20 5 75 30 90
5 127 5.591 142 3.80 4 60 30 90
6 153 6.693 170 6.20 4 60 20 60
8 203 8.622 219 7.00 3 45 10 30
