1 Inch - 4 Inch Reinforced Plastic Hose , PVC Fiber Reinforced Steel Wire Hose / Pipe / Tubing
1 Inch - 4 Inch Reinforced Plastic Hose , PVC Fiber Reinforced Steel Wire Hose / Pipe / Tubing
1 Inch - 4 Inch Reinforced Plastic Hose , PVC Fiber Reinforced Steel Wire Hose / Pipe / Tubing
1 Inch - 4 Inch Reinforced Plastic Hose , PVC Fiber Reinforced Steel Wire Hose / Pipe / Tubing
1 Inch - 4 Inch Reinforced Plastic Hose , PVC Fiber Reinforced Steel Wire Hose / Pipe / Tubing
1 Inch - 4 Inch Reinforced Plastic Hose , PVC Fiber Reinforced Steel Wire Hose / Pipe / Tubing
1 Inch - 4 Inch Reinforced Plastic Hose , PVC Fiber Reinforced Steel Wire Hose / Pipe / Tubing
1 Inch - 4 Inch Reinforced Plastic Hose , PVC Fiber Reinforced Steel Wire Hose / Pipe / Tubing
Specifications
Brand Name :
ET
Model Number :
1/4"-10"
Certification :
ISO9001:2008,SGS,ROHS
Place of Origin :
Shandong, China (Mainland)
MOQ :
1000m
Price :
$0.1-$5 / meter
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
6000tons / year
Delivery Time :
10-15 work days
Packaging Details :
woven plastic cloth wrapped
name :
pvc steel & fiber composite hose
size :
1inch-4inch
inner diameter :
25mm-100mm
thickness :
4mm-8mm
color :
transparent, blue, green etc.
working temperature :
-5℃- 65℃
Description

plastic pvc spiral steel wire and fiber composite reinforced Steel Wire hose / pipe / tubing

specification 1'' -4''
reinforced steel wire and fiber reinforce
length 20m/30m/40m/50m or customized
work pressure 4ar-8bar
standard SGS; ISO
features
flexible, durable, non smell, light weight

pvc steel wire and polyester fiber composite reinforced hose offered come with polyurethane reinforcement which makes them suitable usage in both hot as well as cold working environment. Further, the superior reinforced construction finish of these hoses as well as light weight finish also makes these suitable for use in both indoor as well as applications. Some of its features include extremely lightweight and tough finish, suitable for outdoor or indoor use, withstand constant flexing, light weight finish, small bend radius, resistant to chemicals, water, fuel, oil and others.

Features:

1. Use high - strength fibers and high-quality galvanized spring steel wire as reinforcement.

2. The pressure resistance was enhanced 2-4tims than the single spiral wire reinforced hose

3. flexible, transparent, durable, non-toxic, without odor.

4. anti-erosion and adaption to high pressure.

5. adding colorful symbol lines on the surface of the hose, looking more beautiful

6. elastic, minus pressure resistant and with good adaptability.

Application:

1. conveying powder, grain, water, oil, gas under normal condition or high pressure in the industry, agriculture, irrigation and civil engineering.

2. Can be used for foodstuff, like conveying milk, beverage, distilled, liquor, beer, jam and other foods in vending machine, ice machine.

3. it is the ideal alternative of rubber hose and metal pipe.

Specification:

Inner Diameter Outer Diameter Weight W.P.(at 23℃) Std Length
inch mm inch mm kg/m bar psi m ft
1 25 1.299 33 0.54 8 120 50 150
1-1/4 32 1.614 41 0.78 8 120 40 120
1-1/2 38 1.889 47 1.05 7 105 40 120
2 50 2.441 61 1.60 7 105 40 120
2-1/2 64 3.149 78 2.80 7 105 30 90
3 75 3.582 90 3.50 6 90 30 90
3-1/2 90 4.251 106 4.50 5 75 20 60
4 100 4.645 116 4.80 4 60 20 60

Product tags

pvc steel wire reinforced hose

,

wire reinforced pvc hose

,

pvc spiral steel wire reinforced hose
