High Pressure PVC Steel Wire Hose Non Toxic Transparent Flexible Hose
High Pressure PVC Steel Wire Hose Non Toxic Transparent Flexible Hose
High Pressure PVC Steel Wire Hose Non Toxic Transparent Flexible Hose
High Pressure PVC Steel Wire Hose Non Toxic Transparent Flexible Hose
High Pressure PVC Steel Wire Hose Non Toxic Transparent Flexible Hose
High Pressure PVC Steel Wire Hose Non Toxic Transparent Flexible Hose
Specifications
Brand Name :
ET
Model Number :
1/4"-10"
Certification :
ISO9001:2008,SGS,ROHS
Place of Origin :
Shandong, China (Mainland)
MOQ :
1000m
Price :
$0.1-$5 / meter
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
6000tons / year
Delivery Time :
10-15 work days
Packaging Details :
woven plastic cloth wrapped
material :
pvc, steel wire, fiber
specification :
1inch-4inch
inner diameter :
25mm-100mm
thickness :
4mm-8mm
outer diameter :
33mm-116mm
quality grade :
non-toxic grade
Description

transparent flexible high pressure pvc steel wire fiber composite hose pipe tube

size 1'' -4''
working pressure 4bar-8bar
length 20m/30m/40m/50m or customized
burst pressure 12bar-24bar
application conveying liquid, gas and powder
features
flexible, durable, non smell, light weight

PVC steel & fiber composite hose

The hose, made with steel wire screwing inlaid in the hose, and high quality fiber reinforcement by advanced technology, can keep its shape and work normally under higher pressure as well as minus pressure conditions.

Features:

1. Made of Non-toxic and odor material, good resistant of high temperature and high pressure condition with long life.

2. colorful, light, flexible, durable, elastic, portable and with excellent adaptability
3. Made of special PVC material, high strength fiber and high intensity steel wire

4. Used under 100°C condition, suitable for different high temperature environment

5. By adding colorful symbol lines on the surface of the hose, it looks more beautiful.

6. With high transparency, it is easy to see the flowing of the liquid inside it

7. can be used for conveying milk, beverage, distilled liquor, beer, jam and other liquid food.

Application:

the PVC steel & fiber composite hose is suitable for conveying liquid, gas and powder under high working pressure.

Specification:

Inner Diameter Outer Diameter Weight W.P.(at 23℃) Std Length
inch mm inch mm kg/m bar psi m ft
1 25 1.299 33 0.54 8 120 50 150
1-1/4 32 1.614 41 0.78 8 120 40 120
1-1/2 38 1.889 47 1.05 7 105 40 120
2 50 2.441 61 1.60 7 105 40 120
2-1/2 64 3.149 78 2.80 7 105 30 90
3 75 3.582 90 3.50 6 90 30 90
3-1/2 90 4.251 106 4.50 5 75 20 60
4 100 4.645 116 4.80 4 60 20 60
