PVC Steel Wire Hose / Multipurpose Flexible Spiral Reinforced Plastic Food Grade Hose For Construction
PVC Steel Wire Hose / Multipurpose Flexible Spiral Reinforced Plastic Food Grade Hose For Construction
PVC Steel Wire Hose / Multipurpose Flexible Spiral Reinforced Plastic Food Grade Hose For Construction
PVC Steel Wire Hose / Multipurpose Flexible Spiral Reinforced Plastic Food Grade Hose For Construction
PVC Steel Wire Hose / Multipurpose Flexible Spiral Reinforced Plastic Food Grade Hose For Construction
PVC Steel Wire Hose / Multipurpose Flexible Spiral Reinforced Plastic Food Grade Hose For Construction
PVC Steel Wire Hose / Multipurpose Flexible Spiral Reinforced Plastic Food Grade Hose For Construction
PVC Steel Wire Hose / Multipurpose Flexible Spiral Reinforced Plastic Food Grade Hose For Construction
PVC Steel Wire Hose / Multipurpose Flexible Spiral Reinforced Plastic Food Grade Hose For Construction
PVC Steel Wire Hose / Multipurpose Flexible Spiral Reinforced Plastic Food Grade Hose For Construction
PVC Steel Wire Hose / Multipurpose Flexible Spiral Reinforced Plastic Food Grade Hose For Construction
PVC Steel Wire Hose / Multipurpose Flexible Spiral Reinforced Plastic Food Grade Hose For Construction
Specifications
Brand Name :
ET
Model Number :
1/4"-10"
Certification :
ISO9001:2008,SGS,ROHS
Place of Origin :
Shandong, China (Mainland)
MOQ :
1000m
Price :
$0.1-$5 / meter
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
6000tons / year
Delivery Time :
10-15 work days
Packaging Details :
woven plastic cloth wrapped
name :
clear pvc wire reinforced flexible hose
specification :
3/4''-4''
inner diameter :
6mm-254mm
thickness :
2.5mm-16mm
working temperature :
-5℃ - 65℃
working pressure :
2bar-8bar
length :
20m/30m/40m/50m
color :
transparent, blue, green etc.
Description

PVC Steel Wire Hose / Multipurpose Flexible Spiral Reinforced Plastic Food Grade Hose For Construction

Inner Tube: Clear transparent PVC with smooth wall for reduced resistance and better hygiene

Reinforcement: Steel spiral wire reinforcement or fiber embedded in PVC

Reference Specifications: RoHs standard

Limitations: Pressure ratings provided apply at 20°C and reduce as temperature increases.

Hose Tail Suitability: Industrial fittings, hose clamp or tension bands

Features:

1) Odorless and environmental, feel like rubber, high elasticity, in line with the EU ROHS standard.
2) Not easy to go aging, anti-freeze, sun protective, UV-resistant, high transport, Colorful
3) Products through the ISO quality system certification.
4) The embedded steel wire PVC hose is lightweight and transparent (we can see pipe flow).
5) With the property of small bending radius and good resistance to weather and pressure.
6) To keep original shape in a vacuum and high-pressure condition.
7) You can add color lines on tube surface according to your requirements.
8) Widely used in food, health, and chemical industries.
9) Ideal tube stock to transport water, oil and powder in industry, agriculture and construction.

Applications:

Hard wall hose ideal for agriculture machines (air seeder), marine environments, chemical plants, vacuum trucks and suitable for potable water and foodstuffs. Not recommended for use with petroleum products.

Comments:

Available on special order in different wall thicknesses (changes pressure rating) in MOQ. Contact for details. Rolls, packed in nylon bag as standard or to your specification in MOQ.

Specification of non toxic, food grade, anti staic pvc steel wire reinforced hose:

Inner Diameter Outer Diameter Working Pressure Burst Pressure weight coil
inch mm mm bar psi bar psi g/m m
1/4 6 11 8 120 24 360 115 100
5/16 8 14 8 120 24 360 150 100
3/8 9 15 8 120 24 360 170 100
10 16 8 120 24 360 200 100
1/2 12 18 8 120 24 360 220 100
5/8 15 22 6 90 18 270 300 50
3/4 19 26 6 90 18 270 360 50
7/8 22 27 6 90 18 270 300 50
1 25 33 5 75 16 240 540 50
1-1/4 32 40 5 75 16 240 700 50
1-1/2 38 48 5 75 15 225 1000 50
1-3/4 45 56 5 75 15 225 1300 50
1-7/8 48 59 5 75 15 225 1400 50
2 50 62 5 75 15 225 1600 50
2-5/16 58 69 4 60 12 180 1600 40
2-1/2 64 78 4 60 12 180 2500 30
3 76 90 4 60 12 180 3000 30
3-1/2 90 108 4 60 12 180 4500 20
4 102 116 4 60 12 180 4300 20
4-3/8 110 123 3 45 9 135 4000 20
4-5/8 117 133 3 45 9 135 5500 10
5 127 143 3 45 9 135 6000 10
5-1/2 140 156 3 45 9 135 6500 10
6 152 170 2 30 6 90 8500 10
6-5/16 160 176 2 30 6 90 8500 10
7 180 196 2 30 6 90 8500 10
8 200 224 2 30 6 90 12000 10
10 254 286 2 30 6 90 20000 10
Specification of pvc fiber and steel wire composite reinforced hose:
Inner Diameter Outer Diameter Working Pressure Burst Pressure weight coil
inch mm mm bar psi bar psi g/m m
1 25 33 6 90 18 270 600 50
1-1/4 32 41 5 75 15 225 800 50
1-1/2 38 44 5 75 15 225 900 50
2 50 60 5 75 15 225 1400 50
2-1/2 64 75 4 60 12 180 1800 40
3 75 88 4 60 12 180 2500 40
3-1/2 90 106 4 60 12 180 3700 30
4 102 116 4 60 12 180 4000 30
