PVC High Pressure Suction Hose Clear Plastic Flexible 4 Inch Discharge Hose
PVC High Pressure Suction Hose Clear Plastic Flexible 4 Inch Discharge Hose
PVC High Pressure Suction Hose Clear Plastic Flexible 4 Inch Discharge Hose
PVC High Pressure Suction Hose Clear Plastic Flexible 4 Inch Discharge Hose
Specifications
Brand Name :
ET
Model Number :
1"-6''
Certification :
ISO9001:2008,SGS,ROHS
Place of Origin :
Shandong, China
MOQ :
1000M
Price :
$0.03-$5 / meter
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
6000tons / year
Delivery Time :
10-15 work days
Packaging Details :
transparent plastic film wrapped
Name :
PVC Suction Hose
Colour :
Blue, Red, Yellow, Green, Grey
Material :
PVC
Specification :
3/4"-14"
Working Pressure :
4bar-8bar
Standard :
ISO
Description

PVC High Pressure Suction Hose Clear Plastic Flexible 4 Inch Suction Discharge Hose

specification 25mm to 152mm
color yellow, blue, gray, red, orange, black etc.
length 90ft to 150ft or customized
working pressure 4bar to 8bar
features flexibility, weather, ozone and UV resistant
application sand blasting

Characteristics:

1. Generally black PVC with colorful helix with smooth interior wall

2. Smooth interior prevents material blockage

3. The PVC cover is also weather, ozone and UV resistant

4. Reinforcement is a PVC helix

5. Lightweight and flexible

Feature:

1. Fabric reinforced design with high tensile strength, polyester yarn jacket for handling suction and high pressure discharge applications.

2. The transparent fabric reinforced PVC suction hose allows the user to visually confirm the flow of material and to see if material or condensate has been collected in the tube.

3. The rigid spiral design protects the pipe from cover wear and allows the hose to slide easily over rough surfaces.

4. For general applications such as ice transfer, water transport and other liquids, powder and pellet transport.

Specification:

Inner Diameter Outer Diameter Weight W.P.(at 23℃) Std Length
inch mm inch mm kg/m bar psi m ft
1 25 1.378 35 0.50 8 120 50 150
1-1/4 32 1.654 42 0.60 8 120 50 150
1-1/2 38 1.929 49 0.70 7 100 50 150
2 51 2.520 64 1.05 7 100 50 150
2-1/2 63 3.031 77 1.39 6 90 50 150
3 76 3.622 92 1.70 6 90 30 90
4 102 4.724 120 2.85 5 75 30 90
5 127 5.708 145 3.90 4 60 30 90
6 152 6.732 171 5.00 4 60 30 90
