3 Inch Flexible Vacuum PVC Suction Hose Pipe With High Working Pressures
3 Inch Flexible Vacuum PVC Suction Hose Pipe With High Working Pressures
3 Inch Flexible Vacuum PVC Suction Hose Pipe With High Working Pressures
3 Inch Flexible Vacuum PVC Suction Hose Pipe With High Working Pressures
3 Inch Flexible Vacuum PVC Suction Hose Pipe With High Working Pressures
3 Inch Flexible Vacuum PVC Suction Hose Pipe With High Working Pressures
Specifications
Brand Name :
ET
Model Number :
3/4"-12'' PVC Suction Hose
Certification :
ISO9001:2008,SGS,ROHS
Place of Origin :
Shandong, China
MOQ :
1000m
Price :
$0.03-$5 / meter
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
500tons / month
Delivery Time :
10-15 work days
Packaging Details :
transparent plastic film wrapped
Name :
3 Inch PVC Suction Hose
Thickness :
3mm-12mm
Colour :
Blue, Orange, Yellow, Green, Grey
Features :
abrasion and chemical resistant, impact and crush resistant, etc
Transporting Medium :
liquid, powder, granules
Working Temperature :
-5℃ to +65℃
Description

3 Inch PVC Suction Water Hose Flexible Vacuum Suction Pipe Hose For Sale

Application:
Widely used for heavy duty suction and delivery of water, sewage, oil, greases, debris, gravels in construction buildings, mining industries, water pump industries, and other general industry applications. This kind of suction hose can be used for collection of waste on environmental waste trucks, pumping the contents of grease pits, sewage collection, lubricants and most light chemicals.

Features:
good flexibility
light weight
weather and abrasion resistant
UV resistant
smooth tube prevents materials blockage
smooth outer provides easy dragging
rigid helical reinforcement provides high pressure resistant

Temperature Range -5℃ to +65℃

Remark:
High temperature will reduce the working pressure.
Don't use this hose in applications where static may develop unless grounded.

Specification

Inner Diameter Outer Diameter Weight W.P.(at 23℃) Std Length
inch mm inch mm kg/m bar psi m ft
3/4 19 0.984 25 0.28 8 120 50 150
1 25 1.221 31 0.35 8 120 50 150
1-1/4 32 1.496 38 0.40 7 100 50 150
1-1/2 38 1.811 46 0.65 7 100 50 150
2 51 2.362 60 1.05 6 90 50 150
2-1/2 64 2.913 74 1.30 6 90 30 90
3 76 3.386 86 1.70 5 75 30 90
4 102 4.488 114 3.00 5 75 30 90
5 127 5.512 140 3.60 4 60 30 90
6 153 6.614 168 5.50 4 60 20 60
8 203 8.622 219 7.00 3 45 10 30
10 254 10.787 274 12.00 2 30 10 30
12 305 12.953 329 18.00 2 30 10 30
