Blue 4 Inch Flexible PVC Suction Hose Pipe Spiral Water Pump Suction Hose
Blue 4 Inch Flexible PVC Suction Hose Pipe Spiral Water Pump Suction Hose
Blue 4 Inch Flexible PVC Suction Hose Pipe Spiral Water Pump Suction Hose
Blue 4 Inch Flexible PVC Suction Hose Pipe Spiral Water Pump Suction Hose
Blue 4 Inch Flexible PVC Suction Hose Pipe Spiral Water Pump Suction Hose
Blue 4 Inch Flexible PVC Suction Hose Pipe Spiral Water Pump Suction Hose
Specifications
Brand Name :
ET
Model Number :
3/4"-16''
Certification :
ISO9001:2008,SGS,ROHS
Place of Origin :
Shandong, China
MOQ :
1000M
Price :
$0.03-$5 / meter
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
6000tons / year
Delivery Time :
10-15 work days
Packaging Details :
transparent plastic film wrapped
Work pressure :
2-6bar
Application :
vacuum pumping powder, granules, conveying water
Name :
PVC suction hose
Colour :
Blue, red, orange, white, black, yellow, green, grey
Bursting Pressure :
9bar-30bar
Inner Diameter :
19-408mm
Description

Blue 4 Inch Flexible PVC Suction Hose Pipe Spiral Water Pump Suction Hose

Name Corrugated suction hose / flat pvc suction hose
Color Blue, red, orange, white, black, yellow, green, grey
Length 10m, 20m, 30m, 50m/roll or oem
Working pressure 2bar - 6bar
Temperature Range -5℃ to +65℃

Product features

Soft PVC combined with rigid PVC, both the softness of the hose and the high hardness of the raw material as the support of the ribs, so that the product can not only bend the degree of use, but also greatly improve, the product itself has positive and negative pressure resistance. The inside of the pipe is flat, the water permeability is very high, the wear resistance is good, the weight is very light, the pipe body is rich in anti-UV, anti-aging raw materials, and has high aging resistance. .

Application

It can be widely used in factories, agricultural and hydraulic engineering, vacuum pumping powder, granules, conveying water, oil, etc. It can also transport acid, alkali and other media. It is an excellent substitute for rubber tube and metal tube.

Specification:

Inner Diameter

Outer Diameter

Weight

W.P.(at 23℃)

Std Length

inch

mm

inch

mm

kg/m

bar

psi

m

ft

3/4

19

0.945

24

0.25

6

90

50

150

1

25

1.181

30

0.33

6

90

50

150

1-1/4

32

1.457

37

0.38

6

90

50

150

1-1/2

38

1.732

44

0.58

6

90

50

150

2

51

2.284

58

0.82

5

75

50

150

2-1/2

64

2.835

72

1.17

5

75

30

90

3

76

3.307

84

1.40

4

60

30

90

4

102

4.488

114

2.70

4

60

30

90

5

127

5.512

140

3.60

4

60

30

90

6

153

6.575

167

5.00

3

45

20

60

8

203

8.543

217

6.25

3

45

10

30

10

254

10.787

270

10.00

2

30

10

30

12

305

12.953

329

18.00

2

30

10

30

14

358

15.039

382

20.00

2

30

50

150

16

408

17.008

432

23.00

2

30

50

150
