BLACK MONO Photovoltaic Solar Panel 325 Watt 158.75mm 60cells
BLACK MONO Photovoltaic Solar Panel 325 Watt 158.75mm 60cells
BLACK MONO Photovoltaic Solar Panel 325 Watt 158.75mm 60cells
BLACK MONO Photovoltaic Solar Panel 325 Watt 158.75mm 60cells
Specifications
Brand Name :
SUNERISE
Model Number :
JC325-60M
Certification :
TUV,CQC,CE,IAF,CNAS,ISO etc
Place of Origin :
Hefei,China
MOQ :
30pcs
Price :
Negotiable
Payment Terms :
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability :
1MW,1Month
Delivery Time :
5-7 work days
Packaging Details :
31pcs/palle, packed in cartons
Cell Type :
60pcs 158.75*158.75mm mono cell
Power :
325W+ 0~5W
Voltage :
33.82V
Current :
9.61A
Efficiency :
19.68%
Size :
1665*1002*35mm
Weight :
19.0kg/pcs
Waterproof Grade :
IP68
Description

Top quality BLACK MONO photovoltaic energy 325 watt 158.75mm 60cells small solar panel

Monocrystalline Solar Panel

Top quality BLACK MONO photovoltaic energy 325 watt 158.75mm 60cells small solar panel

Features:

Clean energy, there is no doubt that power companies rely heavily on coal and fossil fuels to generate electricity. Although it may have been the simplest form of energy production, we now have new options. And the air pollution generated by these methods is almost impossible to control. Using solar energy, you can get direct sunlight through solar panels and convert it into usable energy to reduce greenhouse gas emissions.

Maximum Power at STC [Pmax] 325W
Open Circuit Voltage [Voc] 41.1V
Short Circuit Current [Isc] 10.2A
Voltage at Maximum Power Point [Vm] 33.6V
Current at Maximum Power Point [Im] 9.68A
Power Tolerance 0~+5W
Module Efficiency 19.48%
Maximum Power at NOCT [Pmax] 242
Open Circuit Voltage [Voc] 38
Short Circuit Current [Isc] 8.54
Voltage at Maximum Power Point [Vm] 31.6
Current at Maximum Power Point [Im] 7.66
Values at Standard Test Conditions STC Air Mass AM1.5,irradiance 1000W/㎡ ,Cell Temperature 25℃
NOCT Irradiance at 8000W/㎡,Ambient Temperature 20℃,Wind Speed 1m/s


Product details:

Solar cells are a promising new type of power source with three advantages: longevity, cleanliness and flexibility. Solar cells have a long lifespan. As long as the sun exists, solar cells can be invested once and used for a long time; and thermal power generation and nuclear power generation In comparison, solar cells do not cause environmental pollution; solar cells can be large, medium and small, as large as a medium-sized power station of a million kilowatts, as small as a solar battery pack for only one household, which is unmatched by other power sources.

Model : JC325-60M
Cell Type : Mono 158.75*158.75mm* 60pcs
Power : 325W+ 0~5W
Voltage : 33.82V
Current : 9.61A
Efficiency : 19.68%
Dimension : 1665*1002*35mm
Weight : 19.0kg/pcs
Waterproof Grade : IP68
Fireproof Grade : Class C
Package Method : 30 pcs/ pallet
Package size : 1680*1135*1125mm
Package weight : 645Kg
Quantity Of Full Load in 20’ Container : 360
Quantity Of Full Load in 40’ Container : 840
Technique Warranty : 12 years
Generation Warranty : 25 years
OEM/ODM : Accept
MOQ : 30pcs

Manufacturing Technique

BLACK MONO Photovoltaic Solar Panel 325 Watt 158.75mm 60cells BLACK MONO Photovoltaic Solar Panel 325 Watt 158.75mm 60cellsBLACK MONO Photovoltaic Solar Panel 325 Watt 158.75mm 60cells

FAQ
1.Q:Do you have your own factory?
A:Yes, we are professional manufacturer mainly in solar panel for many years. Our factory is located in Hefei, Anhui, China.
2.Q:What kind of certification you have?
A:ISO9001,ISO14001,ISO18001, TUV,CQC,CE,CEC,UL and so on.
Our products could pass different labor testing according to different countries' requirements.
3.Q:Where we can use the system?
A:You can use the system for home, for power station, for lighting system and so on, wnere the grid power is expensive.
4.Q:How about your warranty?
A: We provide 1.5 and 3 years warranty for different products and whole life technical support.
5.Q:Competitive Price
A:All of our products are produced by our own factory. So the price is very copetitive.
6.Q:How to do the installation?
A: This portable solar system installation is very simple, only need to connect solar panel with controller, and push ON/OFF button, then it will start to work.
7.Q:24-hours online service
A: Please feel free to contact us. Our sales team will provide you with 24 hours better pre-sale.
