Specifications
Brand Name :
SUNERISE
Model Number :
JC285-60P
Certification :
TUV , CQC , CE , ISO
Place of Origin :
Hefei,China
MOQ :
31pcs
Price :
Negotiable
Payment Terms :
T/T, L/C
Supply Ability :
1MW,1Month
Delivery Time :
5-8 work days
Packaging Details :
Packed in cartons with 31 pieces per pallet
Solar Cell :
Polycrystalline cell 156.75*156.75
Waterproof Grade :
IP 68
Cable :
4.0mm2 900mm
Size :
1650*992*35mm
Weight :
18KG
Frame :
Anodized Aluminium Alloy
Warranty :
25 years
Application :
Solar Home System
Description

High Quality 285W 60 cells solar panel polycrystalline 18KG IP68 rated for home use

Polycrystalline Solar Panel

High Quality 285W 60 Cells Solar Panel Polycrystalline 18KG IP68 Rated For Home Use


Product specification

Maximum Power at STC [Pmax] 285
Open Circuit Voltage [Voc] 38.30
Short Circuit Current [Isc] 9.64
Voltage at Maximum Power Point [Vm] 31.43
Current at Maximum Power Point [Im] 9.07
Power Tolerance 0~+5W
Module Efficiency 17.52
Maximum Power at NOCT [Pmax] 207.09
Open Circuit Voltage [Voc] 35.26
Short Circuit Current [Isc] 7.83
Voltage at Maximum Power Point [Vm] 28.46
Current at Maximum Power Point [Im] 7.26
Values at Standard Test Conditions STC Air Mass AM1.5,irradiance 1000W/㎡ ,Cell Temperature 25℃
NOCT Irradiance at 8000W/㎡,Ambient Temperature 20℃,Wind Speed 1m/s

Product Details:

Home Use 285W 18KG IP68 Rated Polycrystalline Solar Module
Glass
> Antireflective glass
> Translucency of normal luminance is increased by 2%
> Module efficiency is increased by 2%
> Self-cleaning function
> Service life is as long as 25 years

Home Use 285W 18KG IP68 Rated Polycrystalline Solar Module
Solar Cell
> High Efficiency PV Cells
> Appearance Consistency
> Color sorting ensure consistent appearance on each module
> Anti-PID


Home Use 285W 18KG IP68 Rated Polycrystalline Solar Module
Frame
> Conventional frame
> Silver frames
> Boost bearing capability and prolong service life
> Serrated-clip design tensile strength
> Seal-lip designglue injection
Home Use 285W 18KG IP68 Rated Polycrystalline Solar Module
Junction box
> Conventional standalone edition and engineering custom edition
> Quality diode ensures module running safety
> IP67 protection level
> Heat dissipation
> Long service life

Home Use 285W 18KG IP68 Rated Polycrystalline Solar Module

FAQ

1.Q:Do you have your own factory?

A:Yes, we are professional manufacturer mainly in solar panel for many years. Our factory is located in Hefei, Anhui, China.

2.Q:What kind of certification you have?
A:ISO9001,ISO14001,ISO18001, TUV,CQC,CE,CEC,UL and so on.

Our products could pass different labor testing according to different countries' requirements.

3.Q:Where we can use the system?

A:You can use the system for home, for power station, for lighting system and so on, wnere the grid power is expensive.

4.Q:How about your warranty?

A: We provide 1.5 and 3 years warranty for different products and whole life technical support.

5.Q:Competitive Price

A:All of our products are produced by our own factory. So the price is very copetitive.

6.Q:How to do the installation?

A: This portable solar system installation is very simple, only need to connect solar panel with controller, and push ON/OFF button, then it will start to work.

7.Q:24-hours online service

A: Please feel free to contact us. Our sales team will provide you with 24 hours better pre-sale.

Applications:
Solar power stations.
Rural electrification ,small home power systems.
Power supply for traffic ,security ,gas industry.
12V and 24V battery charging system .
Other industrial and commercial applications.
