Inverter Hybrid Solar Inverter Hybrid Sug Hybrid Inverter 1kw 1.5kw 3kw Hybrid Inverter With Charge Controller
Inverter Hybrid Solar Inverter Hybrid Sug Hybrid Inverter 1kw 1.5kw 3kw Hybrid Inverter With Charge Controller
Specifications
Brand Name :
SUG
Model Number :
SGPE-300W
Certification :
CE & ROHS & FCC & PSE & ISO
Place of Origin :
China
MOQ :
1pcs
Price :
$30-$35
Payment Terms :
T/T, Western Union, Paypal,Alipay
Supply Ability :
10000pcs/month
Delivery Time :
15-20days
Packaging Details :
Carton
Model :
SGPE-300W
Rated Power :
300W
Surge Power :
600W
Input Voltage :
12V/24V/48V(provide input voltage customization)
USB Port :
5V 1A
Output Voltage :
110/220VAC(provide output voltage customization)
Output Frequency :
50HZ or 60HZ
Output Waveform :
Pure Sine Wave
Efficiency :
94% Max.
Product Size :
19.5*11.2*6cm
Meas :
54.5*49*32.5cm/20pcs
N.W./Unit(kg) :
1kg
G.W./Ctn(kg) :
21kg
Output type :
Single
Warranty :
2 Years(start when you sell to your customer)
Description

Inverter Hybrid Solar Inverter Hybrid Sug Hybrid Inverter 1kw 1.5kw 3kw Hybrid Inverter With Charge Controller

This unit is ideal for air-conditioner, pump, microwave oven, refrigerator, coffeemaker, air compressor, electric motor saw, dust collector, TV set, video game, CD player, DVD player, cellular phone chargers and much more!

Model SGPE300A-121 SGPE300A-122 SGPE300A-241 SGPE300A-242 SGPE300A-481 SGPE300A-482
Rated Power 300W
Surge Power 600W(few seconds)
Input Voltage 12VDC 24VDC 48VDC
Output Voltage 110VAC±5% 220VAC±5% 110VAC±5% 220VAC±5% 110VAC±5% 220VAC±5%
USB Port 5V 1A
Frequency 50Hz±3 or 60Hz±3
Output Waveform Pure Sine Wave
Soft Start YES
AC Regulation THD<3%(Linear Load)
Output Efficiency 94% MAX
No Load Current 0.6A 0.3A 0.1A
DC Voltage Range 10-15.5V 20-31V 40-61V
Low Voltage Alarm 10.5±0.5V 21±0.5V 42±1V
Low Voltage Shut Down 10±0.5V 20±0.5V 40±1V
Low Voltage Recovery 13±0.5V 24±0.5V 48±1V
Over Voltage Shut Down 15.5±0.5V 31±0.5V 61±1V
Over Voltage Recovery 14.8V±0.5V 29V±0.5V 59V±1V
Cooling Way Intelligent Cooling Fan
Protection Battery Low Voltage & Over Voltage, Over Load, Over Temperature, Short Circuit, Reverse Polarity
Working Temperature -10ºC - +50ºC
Net Dimension 19.5*11.2*6cm (L×W×H)
Inner Box Dimension 25.6*15*9.8cm (L×W×H)
Meas./Ctn 54.5*49*32.5cm /20 pcs
N.W./Unit 1kg
G.W./Ctn 21KGS
Packing Carton
Warranty 2 Years

Inverter Hybrid Solar Inverter Hybrid Sug Hybrid Inverter 1kw 1.5kw 3kw Hybrid Inverter With Charge Controller

Inverter Hybrid Solar Inverter Hybrid Sug Hybrid Inverter 1kw 1.5kw 3kw Hybrid Inverter With Charge Controller

Inverter Hybrid Solar Inverter Hybrid Sug Hybrid Inverter 1kw 1.5kw 3kw Hybrid Inverter With Charge Controller

Inverter Hybrid Solar Inverter Hybrid Sug Hybrid Inverter 1kw 1.5kw 3kw Hybrid Inverter With Charge Controller

Inverter Hybrid Solar Inverter Hybrid Sug Hybrid Inverter 1kw 1.5kw 3kw Hybrid Inverter With Charge Controller

Inverter Hybrid Solar Inverter Hybrid Sug Hybrid Inverter 1kw 1.5kw 3kw Hybrid Inverter With Charge Controller

Inverter Hybrid Solar Inverter Hybrid Sug Hybrid Inverter 1kw 1.5kw 3kw Hybrid Inverter With Charge Controller

Inverter Hybrid Solar Inverter Hybrid Sug Hybrid Inverter 1kw 1.5kw 3kw Hybrid Inverter With Charge Controller

Inverter Hybrid Solar Inverter Hybrid Sug Hybrid Inverter 1kw 1.5kw 3kw Hybrid Inverter With Charge Controller
