Buzzer Alarm Modified Sine Wave Inverter 1000W 240V Low Voltage Protection
Buzzer Alarm Modified Sine Wave Inverter 1000W 240V Low Voltage Protection
Specifications
Brand Name :
SUG
Model Number :
SGM-500
Certification :
CE & ROHS & FCC & PSE
Place of Origin :
China
MOQ :
1pcs
Price :
Negotiate
Payment Terms :
T/T, Western Union, Paypal
Supply Ability :
10000pcs/month
Delivery Time :
15 working days
Packaging Details :
Carton
Model :
SGM-500
Rated power :
500W
Peak power :
1000W
Input voltage :
12V/24V/48V
Output voltage :
110V/220V/230V/240V
USB Port :
5VDC
Frequency :
50/60Hz±3
Output waveform :
Modified Sine Wave
Efficiency :
More than 85%
Warranty :
12 Months
Type :
DC/AC Inverters
Output type :
Single
Application :
Home Appliance,Solar System,Off-grid System/Car/Boat,vehicle
Soft Start :
Yes
Product Size :
24.5*15*7.7cm (L×W×H)
Meas :
54*34*42cm/8 pcs
N.W./unit(kg) :
1.9kg
G.W./unit(kg) :
18.7KGS
Description

3.5kw Solar Inverter Suoer Inverter Mppt Best Brand Inverter Electric Inverters For House

All Protection:
1. Over-load
2. Over-voltage
3. Low-voltage
4. Buzzer Alarm
5. Short-circuit
6. Over-temperature
Products Specification :
Buzzer Alarm Modified Sine Wave Inverter 1000W 240V Low Voltage Protection
Buzzer Alarm Modified Sine Wave Inverter 1000W 240V Low Voltage Protection

Model SGM1000A-121 SGM1000A-122 SGM1000A-241 SGM1000A-242 SGM1000A-481 SGM1000A-482
Rated Power 1000W
Surge Power 2000W(few seconds)
Input Voltage 12VDC 24VDC 48VDC
Output Voltage 110VAC±5% 220VAC±5% 110VAC±5% 220VAC±5% 110VAC±5% 220VAC±5%
USB Port 5V 1A
Frequency 50Hz±3 or 60Hz±3
Output Waveform Modified Sine Wave
Soft Start YES
AC Regulation THD<3%(Linear Load)
DC Voltage Range 10-15.5V 20-31V 40-61V
Low Voltage Alarm 10.5±0.5V 21±0.5V 42±1V
Low Voltage Shut Down 10±0.5V 20±0.5V 40±1V
Low Voltage Recovery 13±0.5V 24±0.5V 48±1V
Over Voltage Shut Down 15.5±0.5V 31±0.5V 61±1V
Over Voltage Recovery 14.8V±0.5V 29V±0.5V 59V±1V
Cooling Way Intelligent Cooling Fan
Protection Battery Low Voltage & Over Voltage, Over Load, Over Temperature, Short Circuit, Reverse Polarity
Working Temperature -10ºC - +50ºC
Net Dimension 24.5*15*7.7cm (L×W×H)
Inner Box Dimension 28.5*19.2*7.6cm(L×W×H)
Meas./Ctn 54*34*42cm/8 pcs
N.W./Unit 1.9kg
G.W./Ctn 18.7KGS
Packing Carton
Warranty 1 Years


Buzzer Alarm Modified Sine Wave Inverter 1000W 240V Low Voltage Protection
Buzzer Alarm Modified Sine Wave Inverter 1000W 240V Low Voltage Protection
