Y Branch Solar PV Connector 2.5 To 6mm2 Sunlight Resistance Anti Aging
Y Branch Solar PV Connector 2.5 To 6mm2 Sunlight Resistance Anti Aging
Y Branch Solar PV Connector 2.5 To 6mm2 Sunlight Resistance Anti Aging
Y Branch Solar PV Connector 2.5 To 6mm2 Sunlight Resistance Anti Aging
Y Branch Solar PV Connector 2.5 To 6mm2 Sunlight Resistance Anti Aging
Y Branch Solar PV Connector 2.5 To 6mm2 Sunlight Resistance Anti Aging
Specifications
Brand Name :
Hochiry
Model Number :
MCY102
Certification :
TUV
Place of Origin :
CHINA
MOQ :
100 PCS
Price :
3.5USD/PCS
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
50000 Pieces per Week
Delivery Time :
5-8 work days
Packaging Details :
Standard carton(500sets/ctn), 21g/set N.W:10.8KG G.W:11.3KG Size: 40*26*31cm
Rated Voltage :
1000V/1500V
Connector Type :
Male & Female Solar Connector
Test voltage :
8kV(50Hz,1 min)
Contact resistance :
<5mΩ
Pins :
1pin
Contact material :
Copper,Tin plated
Product Name :
Y Branch Connector
Waterproof protection :
IP68
Description
Waterproof IP67 2.5 to 6mm2 Cable Solar Connector

TUV Cable MC4Y5 Connectors PV Connectors Description:
a. Application:Applied to solar panels for power generation and related components of the wiring, connection,particularly suitable for outdoor . Resistance to sunlight, anti-aging , Using the low smoke halogen-free flame retardant materials, higher grade, more safety .
b. Construction:MC4 Y Solar PV Connector, with TUV certified, has inner drum-type material metal connectors, the plugs and minus connector are used with the cable, made of PC material, easy to connector with each other. It is important and indispensable components for photoelectric system.

TUV Cable MC4Y5 Connectors PV Connectors Advantages:
a. Simple on-site processing
b. Mating safety provided bykeyed housings
c .Multiple plugging and unplugging cycles
d. Accomodates PV cable with different insulation diameters
e. High current carrying capacity
f. TUV and UL approved

TUV Cable MC4Y5 Connectors PV Connectors Technical Data:
Product Name MC4Y5 Connector
Rated Current 30A(2.5~6mm2)
Rated Voltage 1000V DC
Test Voltage 6000V(50HZ, 1min)
Overvoltage category/Pollution degree CAT III/2
Contact resistence of plug connectors 1 mΩ
Conatct material Copper, Ag plated
Insulation material PPO
Degree of protection IP20/IP67
Flame class UL94-V0
Safety class II
Suitable cable 2.5-6mm2
Insertion force/Withdrawal force ≤50N/ ≥50N
Connecting system Crimp connection
Temperature range -40ºC~+125ºC
Packing unit 1000pcs
Minimum order quantity 1000pcs
Weight per Piece (excluding packing) 25g
Custom tariff number 8536690000
Country of origin China
