12F Overhead Outdoor Fiber Optic Cable GYXFTY G655 G652D G657A Non Metallic
12F Overhead Outdoor Fiber Optic Cable GYXFTY G655 G652D G657A Non Metallic
12F Overhead Outdoor Fiber Optic Cable GYXFTY G655 G652D G657A Non Metallic
12F Overhead Outdoor Fiber Optic Cable GYXFTY G655 G652D G657A Non Metallic
12F Overhead Outdoor Fiber Optic Cable GYXFTY G655 G652D G657A Non Metallic
12F Overhead Outdoor Fiber Optic Cable GYXFTY G655 G652D G657A Non Metallic
Specifications
Brand Name :
Hochiry
Model Number :
GYTXW Fiber Cable
Certification :
CE/ROHS/ISO9001/ANATEL
Place of Origin :
CHINA
MOQ :
10000 meter
Payment Terms :
T/T, Western Union, MoneyGram
Product Name :
GYTXW Fiber Cable
Fiber Options :
G652D ,G657A,OM1,OM2,OM3,OM4
Strength member: :
Double parallel FRP or Steel Wire
Jacket :
PE
Fiber Count :
1-12 Fibers
Type :
Central Loose Tube
Application :
Aerial
Length :
2km or customized length
Structure :
Loose tube
Description

Nonmetal G655 G652D G657A 12F Overhead Outdoor Round Fiber Optic Drop Cable GYXFTY

Description:

GYXFTY fiber optic cable is a non-metallic all dielectric cable used for power transmission system, excessive thunder areas and high electromagnetic interface. The cable tubes, which are filled with filling compound, there is a central loose tube, and with parallel FRP strength member. the cable is completed with a PE sheath. GYXFTY cables are available from 2 core to 12 core. It is used in high-voltage area for long distance aerial or duct application


Features:

1. GYXFTY cable complies with Standard YD/T 769-2003.
1. Good mechanical and temperature performance
2. High strength loose tube that is hydrolysis resistant
3. Special tube filling compound ensure a critical protection of fiber
4. Crush resistance and flexibility
5. PSP enhancing moisture-proof
6 . Two parallel steel wires ensure tensile strength
7. Small diameter, light weight and friendly installation
8. Long delivery length


Technical Parameters:

Cable Type Fiber Count Cable Diameter Cable Weight Tensile Strength Crush Resistance Bending Radius
Long/Short Term Long/Short Term Static/Dynamic
mm kg/km N N/100mm mm
GYXS/GYXTW-2~12 2~12 10 105 600/1500 300/1000 10D/20D
GYXS/GYXTW-2~12 2~12 10.6 124 1000/3000 1000/3000 10D/20D
GYXS/GYXTW-14~24 14~24 12.5 149 1000/3000 1000/3000 10D/20D
GYXS/GYXTW-26~36 26~36 14 190 1000/3000 1000/3000 10D/20D
GYXS/GYXTW-38~48 38~48 15 216 1000/3000 1000/3000 10D/20D

12F Overhead Outdoor Fiber Optic Cable GYXFTY G655 G652D G657A Non Metallic


Package and Delivery

12F Overhead Outdoor Fiber Optic Cable GYXFTY G655 G652D G657A Non Metallic
