156mm*156mm Mono / Photovoltaic Cell Solar Panel 420 Watt 400W 410W
156mm*156mm Mono / Photovoltaic Cell Solar Panel 420 Watt 400W 410W
156mm*156mm Mono / Photovoltaic Cell Solar Panel 420 Watt 400W 410W
156mm*156mm Mono / Photovoltaic Cell Solar Panel 420 Watt 400W 410W
Specifications
Brand Name :
Hochiry
Certification :
TUV
Place of Origin :
CHINA
MOQ :
100PCS
Payment Terms :
T/T, Western Union, MoneyGram
Delivery Time :
20-25 work days
Packaging Details :
27pcs/ per pallet 270pcs/ 1*20' container 648pcs/ 1*40' container
Product name :
Solar PV Photovoltaic PERC Panel Module
Solar cell :
Mono 156mm*156mm
Solar power (w) :
2000W
Max. power :
420 Watt 400W 410W
Frame :
Anodized Aluminium Alloy
Material :
Monocrystalline Silicon
Warranty :
25 Years Output Power Guarantee
Number of cells :
60(6*10)Pcs/72(6*12) Pcs/78(6*13) Pcs
Panel Efficiency :
High Efficiency 144cells
Solar Cells :
Monocrystalline,Polycrystalline,Amorphous Silicon
Glass :
3.2mm High Transmission Tempered Glass
Description
420 Watt Monocrystalline Solar Panels 400W 410W Half Cell Solar Photovoltaic Cell Solar Panel
Products Description
Electrical Characteristics(STC)
Module Type
SW395M-72
SW400M-72
SW405M-72
SW410M-72
SW420M-72
Maximum Power (Pmax)
395W
400W
405W
410W
420W
Maximum Power Voltage (Vmp)
41.50V
41.80V
42.10V
42.30V
42.50V
Maximum Power Current (Imp)
9.52A
9.57A
9.62A
9.70A
9.88A
Open-circuit Voltage (Voc)
49.40V
49.60V
49.80V
50.00V
50.20V
Short-circuit Current (Isc)
10.12A
10.16A
10.21A
10.25A
10.45A
Module Efficiency (%)
19.62%
19.87%
20.11%
20.36%
20.85%
Power Tolerance
0~+5W
Temperature Coeffcient of Isc
+0.05%/℃
Temperature Coeffcient of Voc
-0.29%/℃
Temperature Coeffcient of Pmax
-0.37%/℃
Glass
* Anti-reflective glass
* High-transmittance and low reflection Increase model efficiency
* High mechanical strength
Solar Cell
* High model efficiency up to 20% *High shunt-resistance: adapt the several environmental conditions
* High PID resistant
* Low breakage rate
* Uniform color
Frame
* Optional silvery or black frame
* Tensile Strength Frame
* Boost bearing capability and prolong service life
Junction Box
* Waterproofness Junction Box
* Innovative Full-Glue-Filled Combination of series circuit and parallel circuit, reduced internal
power loss Quality diode ensures module running safety
* Heat dissipation
* Long service life
