Bifacial Mono Solar Panel PV Module 400W 500W 550W 156mm*156mm Cell
Bifacial Mono Solar Panel PV Module 400W 500W 550W 156mm*156mm Cell
Bifacial Mono Solar Panel PV Module 400W 500W 550W 156mm*156mm Cell
Bifacial Mono Solar Panel PV Module 400W 500W 550W 156mm*156mm Cell
Specifications
Brand Name :
Hochiry
Certification :
TUV
Place of Origin :
CHINA
MOQ :
100PCS
Payment Terms :
T/T, Western Union, MoneyGram
Delivery Time :
20-25 work days
Packaging Details :
27pcs/ per pallet 270pcs/ 1*20' container 648pcs/ 1*40' container
Product name :
Solar Panel PV Module
Solar cell :
Mono 156mm*156mm
Material :
Monocrystalline Silicon
Number of cells :
60(6*10)Pcs/72(6*12) Pcs/78(6*13) Pcs
Solar power (w) :
2000W
Max. power :
450W 550W 600W
Solar Cells :
Monocrystalline,Polycrystalline,Amorphous Silicon
Frame :
Anodized Aluminium Alloy
Warranty :
25 Years Output Power Guarantee
Panel Efficiency :
High Efficiency 144cells
Glass :
3.2mm High Transmission Tempered Glass
Description
Mono Solar Panel Bifacial 400W 500W 550W Solar Panel PV Module
Products Description
600W+ Ultra-high Power with 21.4% High Efficiency Based on the 210mm large-size silicon wafer and monocrystalline PERC cell, allowing high power output of more than 600W. Excellent temperature coefficient and low irradiation performance brings the greater power. Furthermore, benefit from square mono cells and high-density encapsulation technology, the efficiency of can reach up to 21.4%.
Electrical Characteristics(STC)
Module
Mono 400W-600W+
Maximum Power (Pmax)
400Wp
500Wp
550Wp
600Wp
Maximum Power Voltage (Vmp)
34.2V
42.8V
31.8V
34.6V
Maximum Power Current (Imp)
11.70A
11.69A
17.29A
17.34A
Open-circuit Voltage (Voc)
41.2V
51.7V
38.1V
41.7V
Short-circuit Current (Isc)
12.28A
12.28A
18.39A
18.42A
Module Efficiency (%)
20.8%
20.9%
21.0%
21.2%
Power Tolerance
0~+5W
NOCT(Nominal Operating Cell Temperature)
43°C (±2°C)
Temperature Coefficient of PMAX
- 0.34%/°C
Temperature Coefficient of VOC
- 0.25%/°C
Temperature Coefficient of ISC
0.04%/°C
Operational Temperature
-40~+85ºC
Maximum System Voltage
1500V DC (IEC) 1500V DC (UL)
Max Series Fuse Rating
35A
Product Display
Glass
*Anti-reflective glass
*High-transmittance and low reflection Increase model efficiency
*High mechanical strength

Solar Cell
*High model efficiency up to 20%
*High shunt-resistance: adapt the several environmental conditions
*High PID resistant
* Low breakage rate
*Uniform color

Frame
*Optional silvery or black frame
* Tensile Strength Frame
*Boost bearing capability and prolong service life

Junction Box
*Waterproofness Junction Box
*Innovative Full-Glue-Filled Combination of series circuit and parallel circuit, reduced internal power loss Quality diode ensures module running safety
*Heat dissipation
*Long service life
