Pyrolysis Batch Type Plastic Waste To Diesel Fuel Oil
Pyrolysis Batch Type Plastic Waste To Diesel Fuel Oil
Pyrolysis Batch Type Plastic Waste To Diesel Fuel Oil
Pyrolysis Batch Type Plastic Waste To Diesel Fuel Oil
Specifications
Brand Name :
Huayin
Model Number :
HY-10ton
Certification :
CE ISO
Place of Origin :
Xinxiang city, Henan,China
MOQ :
1 set
Price :
USD35000-45000 per set
Payment Terms :
L/C, T/T
Supply Ability :
220 sets per year
Delivery Time :
15-25 work days
Packaging Details :
plastic flims for pyrolysis reactor , wooden boxes for small parts
Product name :
batch type pyrolysis plant for plastic pyrolysis machine waste plastic to oil
Function :
waste plastic to diesel machine
Rotating speed :
0.4 turn/minute
Input raw material: :
waste tyres, plastic, pmma
Output product :
Fuel oil , Carbon black ,steel wire, syngas
Opeartor :
3-4 workers
Heating fuel :
Wood /Coal /Gas /Oil
type :
batch type
Description

Batch Type Pyrolysis Plant For Plastic Pyrolysis Machine Waste Plastic To Oil

Product description

The function of the waste tire/plastic pyrolysis plant is to convert various kinds of waste tires like car tyres , motorcycle tires, bicycle tires, and OTR tires , plastic scrap to fuel oil, carbon black, steel wire, and syngas. Due to the advantages of environmentally friendly, energy-saving, high safety level, and large profit of this equipment, it is widely used for the treatment of waste rubber and plastic products.

Specification

Item Content
Raw materials Waste tyre/rubber/plastic
Output Fuel oil, carbon black, steel wire, syngas
Model Reactor size Capacity
HY1500*3000 1 T/batch
HY2200*5500 5 T/batch
HY2200*7500 7 T/batch
HY2600*6600 8 T/batch
HY2800*6000 9 T/batch
HY2800*6600 10 T/batch
HY2800*8000 15 T/batch
Remarks Support customization
Reactor material and thickness

Q345R/Q245R/310S (Boiler plate/stainless steel)

16mm/18mm
Land area 300-400㎡ (L30-40m*W10m)
Number of workers 3-4
Oil density and calorific value 0.89g/cm³&44.30KJ/KG
Processing time and power 10-24 hours. Averagely 15KW/h
Certification CE, ISO, BV, SUV, SGS Oil Report, Emission Report, 11 patents

Pyrolysis Batch Type Plastic Waste To Diesel Fuel Oil

Main features

1. High efficiency. The feeding port of the pyrolysis reactor is 1400mm, so the waste material doesn’t need pretreatment, it can be put into the pyrolysis reactor directly with the auto feeder machine.

2. High stability. The rollers are engineered underfeeding port and oil outlet port which are external from the heating area to bring perfect rotating balance and longer service life.

3. Energy saving: Non-condensable gas will go back to the heating system for second burning as heating material, saving your heating fuel.

4. High oil yield: Larger condensation area to ensure sufficient condensation of oil gas into liquid oil.

5. Eco-friendly: The stainless steel deduster is filled with ceramic filters inside, which brings it strong dust adsorption capacity and a good dedusting effect.

6. High safety level: Equipped with Alarm, auto pressure releasing device, anti backfire device, vacuum pump to ensure the machine working smoothly.

Pyrolysis Batch Type Plastic Waste To Diesel Fuel Oil

Pyrolysis Batch Type Plastic Waste To Diesel Fuel Oil

Output product and usage

Fuel Oil (50%-75%)

1. Used as the heating material and sell it to cement factories, glass factories, ceramic factories, electric power factories, steel making factories, boiler factories, etc.
2. Used in heavy oil generator for electricity generation.
3. Deep process it into diesel oil with our distillation plant, color and smell removal system, the final oil can be used in diesel engines like trucks, tractors, etc.

Carbon Black (30%-35%)

Slag for construction.

Flammable Gas (8%-10%)

1. Recycled into the furnace to heat reactor instead of coal/wood/oil/natural gas.
2. Storage the extra gas to restart the next batch.

Profit analysis

Project Qty. Unit Price Cost/Day Cost/Month (25Days) Cost/Year (10Months)
(MT) (USD) (USD) (USD) (USD)
Production cost
A,Waste plastic 10 295.00 2,950.00 73,750.00 737,500.00
B,Electric 300KW 0.059 17.70 442.50 4,425.00
C,Fuel(Coal) 0.25 649.00 162.25 4,056.25 40,562.50
D,Labor(4 workers) 4 4.73 64.00 1,600.00 16,000.00
Total 3,193.95 79,848.75 798,487.50
Sales Income
A,Fuel Oil (70%) 7.0 649.00 4,543.00 113,575.00 1,135,750.00
B,Carbon Black(20%) 2.0 165.00 330.00 8,250.00 82,500.00
Total 9 814.00 4,873.00 121,825.00 1,218,250.00
Factory Profit 1,679.05 41,976.25 419,762.50
