Specifications
Brand Name :
Huayin
Model Number :
HY-5T
Certification :
CE ISO
Place of Origin :
xinxiang , Henan , China
MOQ :
1set
Price :
USD35000-69000/set
Payment Terms :
L/C, T/T
Supply Ability :
250sets per year
Delivery Time :
15 working days
Packaging Details :
plastic flims for pyrolysis reactor , wooden boxes for small parts
Type :
Batchy type
Reactor material :
Q345R/Q245R boiler plate,support customized
Input raw material :
waste plastic ,PP PE PS , used rubber , tires
Output product :
Fuel oil , Carbon black , Steel wire, gas
Capacity :
1-15ton per batch
Landing area :
250-300 square meter
Description

Small Waste Plastic To Diesel Oil Machine Pyrolysis Plant Easy Operating

1. Capacity from 1 ton-15ton capacity per batch.

2. Fast installation design & Bulk type design &Container design

3. Different designs for the dedusting systems to meet the emission requirements of different countries.

Batchy type Turning Plastic Into Diesel Fuel

Output product

If you want to get diesel as the final product, then you need pyrolysis plant + pyrolysis oil distillation plant and color and smell removal system together. we provide the complete production line. We have tested each kind of oil, so we could provide SGS analysis report for you .

Batchy type Turning Plastic Into Diesel Fuel

Application of the output product

1. Fuel oil: Widely used as fuel oil in industries such as steel and iron factories, ceramics or chemical industries or hotels, restaurants etc. or used for generators to get electricity.

2. Carbon black: used for construction bricks with clay, also can be used as fuel.

3. Steel wires: Sold or reprocessing

4. Combustible gas: Can be recycled and used during process as fuel.

Specification

Model HY-05 HY-08 HY-10 HY-15
Raw material Waste rubbers/tyres/plastic
Output product 45% fuel oil, 30% carbon black, 10% steel wire, 10%-15% syngas
Daily Handling capacity 5 tons 8 tons 10 tons 12 tons
Machine dimension(mm) D2200*L5500 D2600*L6600 D2800*L6600 D2800*L8000
Landing Area 200m2 250m2 300m2 350m2
Working pressure Normal pressure
Main engine rotating speed 0.4R /min
Power 15KWH
Cooling Mode Circle Water
Heating Mode Direct
Oil Yield 40%-50%
Noise dB (A) <=85
Working Mode Batch type

Detail Images

Batchy type Turning Plastic Into Diesel Fuel

Batchy type Turning Plastic Into Diesel Fuel

Our services

1. One-stop solution. We have 28 years of rich manufacturing experience and a good reputation. We attach great importance to customer experience and satisfaction.We are able to provide you with a whole high-quality product line.
2. We have our own factory and trading company, no middlemen, all products provide you with ex-factory prices, it is more convenient for you to replace related parts (as long as there is a problem, we can provide a solution immediately, product quality is guaranteed.
3. We promise that our products are efficient and have a long service life to ensure that you can quickly produce in batches.
4. Very short delivery time.
5. We can send engineers on-site to guide installation and train your workers, Lifelong maintenance, providing professional use guidance services.

Batchy type Turning Plastic Into Diesel Fuel
