CE Plastic To Diesel Machine Huayin , 10 Ton Plastic Into Diesel Fuel
CE Plastic To Diesel Machine Huayin , 10 Ton Plastic Into Diesel Fuel
CE Plastic To Diesel Machine Huayin , 10 Ton Plastic Into Diesel Fuel
CE Plastic To Diesel Machine Huayin , 10 Ton Plastic Into Diesel Fuel
Specifications
Brand Name :
Huayin
Model Number :
HY-10ton
Certification :
CE ISO
Place of Origin :
Xinxiang city, Henan,China
MOQ :
1 set
Price :
USD35000-45000 per set
Payment Terms :
L/C, T/T
Supply Ability :
220 sets per year
Delivery Time :
15-25 work days
Packaging Details :
plastic flims for pyrolysis reactor , wooden boxes for small parts
Product name :
Large Profit Plastic To Diesel Recycling Waste Plastic To Fuel Oil Machine Plants With CE
Rotating speed :
0.4 turn/minute
Input raw material: :
waste tyres, plastic, pmma
Output product :
Fuel oil , Carbon black ,steel wire, syngas
Function :
waste plastic to diesel machine
Opeartor :
3-4 workers
Heating fuel :
Wood /Coal /Gas /Oil
type :
batch type
Description

Large Profit Plastic To Diesel Recycling Waste Plastic To Fuel Oil Machine Plants With CE

Product description

The plastic waste that can be seen everywhere seriously pollutes our living environment, how to dispose of this plastic waste properly is increasingly important. Huayin waste plastic pyrolysis plant can recycle the waste plastic to fuel oil, carbon black, and gas through pyrolysis technology, the whole process is environmentally friendly and brings you large profit .

Specification

Item Content
Raw materials Waste tyre/rubber/plastic
Output Fuel oil, carbon black, steel wire, syngas
Model Reactor size Capacity
HY1500*3000 1 T/batch
HY2200*5500 5 T/batch
HY2200*7500 7 T/batch
HY2600*6600 8 T/batch
HY2800*6000 9 T/batch
HY2800*6600 10 T/batch
HY2800*8000 15 T/batch
Remarks Support customization
Reactor material and thickness

Q345R/Q245R/310S (Boiler plate/stainless steel)

16mm/18mm
Land area 300-400㎡ (L30-40m*W10m)
Number of workers 3-4
Oil density and calorific value 0.89g/cm³&44.30KJ/KG
Processing time and power 10-24 hours. Averagely 15KW/h
Certification CE, ISO, BV, SUV, SGS Oil Report, Emission Report, 11 patents

CE Plastic To Diesel Machine Huayin , 10 Ton Plastic Into Diesel Fuel

Output product and usage

Fuel Oil (50%-75%)

1. Used as the heating material and sell it to cement factories, glass factories, ceramic factories, electric power factories, steel making factories, boiler factories, etc.
2. Used in heavy oil generator for electricity generation.
3. Deep process it into diesel oil with our distillation plant, color and smell removal system, the final oil can be used in diesel engines like trucks, tractors, etc.

Carbon Black (30%-35%)

Slag for construction.

Flammable Gas (8%-10%)

1. Recycled into the furnace to heat reactor instead of coal/wood/oil/natural gas.
2. Storage the extra gas to restart the next batch.

CE Plastic To Diesel Machine Huayin , 10 Ton Plastic Into Diesel Fuel

Main features

1. High automation: Loading used tires/plastic into the pyrolysis reactor with 50ton hydraulic pressure, so the auto feeder can help you save labor and load more waste raw material, compared with manual feeding, the automatic feeder is more efficient.

2. 100% safety: The pyrolysis reactor is made of Q245R/Q345R boilerplate, which is high pressure and high-temperature resistance that ensure its longer service life. Adding perfect hot seal technology to ensure operation safely.

3. Environmental friendly: Flue gas is purified by ceramic packing dedusting device, finally no black smoke emitted.

4. High efficiency discharging device: Discharge carbon black from pyrolysis reactor after the production is finished in a sealed condition, no pollution and saves labor and time.

5. Strictly quality control. All of the steel plates are purchased from China's famous company " Anyang Iron and Steel Co., Ltd ", and the raw material inspection certificate can be provided to customers. For each set of machines, we will do ultrasonic nondestructive testing, and automatic submerged welding technology to ensure the machine quality.

CE Plastic To Diesel Machine Huayin , 10 Ton Plastic Into Diesel Fuel

Profit analysis report

Project Qty. Unit Price Cost/Day Cost/Month (25Days) Cost/Year (10Months)
(MT) (USD) (USD) (USD) (USD)
Production cost
A,Waste plastic 10 295.00 2,950.00 73,750.00 737,500.00
B,Electric 300KW 0.059 17.70 442.50 4,425.00
C,Fuel(Coal) 0.25 649.00 162.25 4,056.25 40,562.50
D,Labor(4 workers) 4 4.73 64.00 1,600.00 16,000.00
Total 3,193.95 79,848.75 798,487.50
Sales Income
A,Fuel Oil (70%) 7.0 649.00 4,543.00 113,575.00 1,135,750.00
B,Carbon Black(20%) 2.0 165.00 330.00 8,250.00 82,500.00
Total 9 814.00 4,873.00 121,825.00 1,218,250.00
Factory Profit 1,679.05 41,976.25 419,762.50

Installation cases show
