12 Tonnes Small Pyrolysis Tire Recycling System In Poland To Fuel Oil
12 Tonnes Small Pyrolysis Tire Recycling System In Poland To Fuel Oil
12 Tonnes Small Pyrolysis Tire Recycling System In Poland To Fuel Oil
12 Tonnes Small Pyrolysis Tire Recycling System In Poland To Fuel Oil
Specifications
Brand Name :
Huayin
Model Number :
HY-12ton
Certification :
CE ISO
Place of Origin :
Xinxiang city, Henan,China
MOQ :
1 set
Price :
USD32000-48000 per set
Payment Terms :
L/C, T/T
Supply Ability :
220 sets per year
Delivery Time :
15-25 work days
Packaging Details :
plastic flims for pyrolysis reactor , wooden boxes for small parts
Product name :
small tire pyrolysis plant 12 tonnes in poland tyre recycling machine to fuel oil
Input raw material: :
waste tyres, plastic, pmma
Output product :
Fuel oil , Carbon black ,steel wire, syngas
Function :
tyre to oil pyrolysis plant
Rotating speed :
0.4 turn/minute
Opeartor :
3-4 workers
Heating fuel :
Wood /Coal /Gas /Oil
type :
batch type
Description

Small Tire Pyrolysis Plant 12 Tonnes In Poland Tyre Recycling Machine To Fuel Oil

Product description

With the increasing awareness of environmental protection in the world, the harmless and resourceful disposal of waste tires/plastic has become an important trend. The waste plastic /tyre recycle to fuel oil machinery is designed to process the waste into valuable products -industrial fuel oil, carbon black, and steel wire through catalytic cracking technology. This green technology has created good economic and social benefits.

12 Tonnes Small Pyrolysis Tire Recycling System In Poland To Fuel Oil

Output product and usage

12 Tonnes Small Pyrolysis Tire Recycling System In Poland To Fuel Oil

Output Products Application
Fuel Oil (40%-55%) 1. Used as the heating material and sell it to cement factories, glass factories, ceramic factories, electric power factories, steel making factories, boiler factories, etc.
2. Used in heavy oil generator for electricity generation.
3. Deep process it into diesel oil with our distillation plant, color, and smell removal system, the final oil can be used in trucks, tractors, etc.
Carbon Black (30%-35%) 1. Make it to pellet or briquette as heating material.
Steel Wire (10%-15%) Sell to iron and steel factory directly.
Flammable Gas (8%-10%)

1. Recycled into the furnace to heat reactor instead of heating material.

2. Storage the excess gas to restart the next batch.

Main features

Our advantage
Reactor material Adopt Q245R/Q235R high pressure and temperature resistance steel plate to ensure longer service life. For some special raw materials, we use a special steel plate.
High efficiency discharging Adopt screw conveyor discharging device, discharge carbon black in sealed condition, no pollution, and save labor and time.
Integrated condensing device All of the condensing parts have been installed together before delivery from the factory, saving installation time and ensuring welding quality
Auto feeding system Auto feeder machine to feed raw material automatically, save labor and time.
Energy saving

The inner reactor body and outside insulation cover have good airtightness, avoiding heating loss and saving fuel.

The combustible gas (that cannot be further cooled down into fuel oil )will be recycled into the furnace for heating the reactor, maximizing resource utilization.
Valves All of the valves use stainless steel.
Non-pollution Adopt 3 layers of ceramic packing dedusting device and water spray, finally, no black smoke discharged out. SGS emission report provided.
Safety devices Alarm, auto pressure releasing device, anti backfire device, vacuum pump to ensure the machine working smoothly.

12 Tonnes Small Pyrolysis Tire Recycling System In Poland To Fuel Oil12 Tonnes Small Pyrolysis Tire Recycling System In Poland To Fuel Oil

Specification

Item Content
Raw materials Waste tyre/rubber
Output 45% fuel oil, 30% carbon black, 10% steel wire, 10%-15% syngas
Model Reactor size Capacity
HY1500*3000 1 T/batch
HY2200*5500 5 T/batch
HY2200*7500 7 T/batch
HY2600*6600 8 T/batch
HY2800*6000 9 T/batch
HY2800*6600 10 T/batch
HY2800*8000 15 T/batch
Remarks Support customization
Reactor material and thickness

Q345R/Q245R/310S (Boiler plate/stainless steel)

16mm/18mm
Land area 300-400㎡ (L30-40m*W10m)
Number of workers 3-4
Oil density and calorific value 0.89g/cm³&44.30KJ/KG
Processing time and power 10-24 hours. Averagely 15KW/h
Certification CE, ISO, BV, SUV, SGS Oil Report, Emission Report, 11 patents

Our services

1. With over 20 years of manufacturing experience, we are confident to provide you with a quality pyrolysis plant at the most reasonable price.

2. Very short delivery time. The delivery time is usually 15 working days.

3. We can send engineers on-site to guide installation and train your workers, providing professional use guidance services.

4. One-year warranty, lifelong maintenance of the equipment, providing professional use guidance services.

12 Tonnes Small Pyrolysis Tire Recycling System In Poland To Fuel Oil
