Specifications
Place of Origin :
Guangdong, China (Mainland)
Brand Name :
HAIDA
Certification :
ISO 9001:2000; ISO 9001:2008; QS-9000; ISO 14001:2004; CE, , SMC, CMC, CPA, CE,CMA,IMC
Model Number :
HD-X003-2
Power :
Electronic
Port :
ShenZhen
MOQ :
1 Set
Price :
Negotiable
Packaging Details :
ach set protected with resin fiber and PP film, then put into Strong wooden case with operation man
Delivery Time :
20 days after order confirmed
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram,In cash, escrow
Supply Ability :
300 Sets per Month Haida
Usage :
Paper Testing Instrument
Dimensions (W × H × D) mm :
102 × 244 × 63mm
The shortest interval :
three seconds can be determined
Display :
color values, color values, pass / warning / fail
LCD :
English (default), German, French, Italian, Spanish, Japanese
Description

High Powerful Paper Testing Equipments Hardness For Residential Construction

Colorimeter HD-X003-2(CR400)

The new Konica Minolta "CR-400", "CR-410" colorimeter can be measured by measuring the head monomer, which has high accuracy and are versatile and easy to operate.

Type ---- reflective color measurement

Main use: paint, rubber, plastics, printing, fiber, dyeing, food, agriculture, forestry, fisheries, ceramics, nitrogen products, residential construction, medical and academic fields

Colorimeter Products

Renowned color colorimeter series - more powerful and diverse

Colorimeter from the famous series, more powerful and diverse.

New colorimeter CR-400 is a widely recognized and acclaimed CR-100, CR-200, CR-300 series successor. It has a lot of additional features, more versatile, but fully retained the all-optical characteristics, so make sure you can exchange data with the previous model. CR-400 measuring area of 8mm, suitable for measuring various industries reflected color and color difference. It can meet the ingredients, food, raw materials, finished goods, drugs and dermatology, and many other applications

Colorimeter Main Specifications

Name colorimeter measuring head
Model CR-400 measuring head CR-410 measuring head
Lighting / receiving optical system d / 0 (diffuse illumination light perpendicular manner; specular component included) (With JIS Z 8722 standard; including regular reflection light) large area lighting vertical light way; specular component included)
Light sub-prime silicon photocell (6)
Display range Y 0.01% ~ 160.00% (reflectance)
Measuring light source pulsed xenon arc lamp
Measuring time 1 s
The shortest interval three seconds can be determined
Measurable frequency 800 times (my company under specified conditions)
Measurement / illumination area Φ8mm / Φ11mmΦ50mm/Φ53mm
Repeatability standard deviation ΔE * ab 0.07 or less (in 10 seconds after white calibration measured 30 times at intervals)
Instrument error ΔE * ab 0.6 or less
BCRA Series II 12 colors mean ΔE * ab 0.8 or less
BCRA Series II 12 colors mean
Viewing conditions CIE2 ° approximate color vision functions such as Observation light source * C, D65
Display color values, color values, pass / warning / fail
Eligibility determination color difference threshold (box / oval critical)
Chromaticity diagram / table color value XYZ, Yxy, L * a * b *, search Lab, L * C * h, Husserl (only illuminant C), CMC (l: c) , CIE1994, Lab99, LCh99 , CIE2000, CIE WI / Tw (only illuminant D65), WI ASTM E313 (only illuminant C), YI ASTM D1925 (only illuminant C), YI ASTM E313 (only illuminant C), users retrieve (can register up to 6 from a computer )
Use language operating buttons English
LCD English (default), German, French, Italian, Spanish, Japanese
Save Data Quantity 1000 data (measuring head and data processor save different content)
Color reference color 100
Correction Channel 20 channels (ch00: white calibration, ch01 ~ ch19: Any correction)
Backlit dot matrix LCD display 15 characters × 9 lines + icon displays a row
Interfaces RS-232 standard connection data processor / PC
Baud rate 4800,9600,19200 (bps); factory-set to 9600bps
Power 4 AAA-size alkaline or Ni-MH batteries or the AC adapter AC-A17 AC120V 50-60Hz 0.4A (for North America and Japan) AC230V 50-60Hz 0.4A (for countries or regions outside of North America)
Dimensions (W × H × D) mm

102 × 244 × 63mm
Weight approx 550g (Including 4 AAA batteries, excluding RS-232C cable) approx 570g (Including 4 AAA batteries, excluding RS-232C cable)
Operating temperature / humidity range 0 ~ 40 ° C, relative humidity 85% or less with no condensation
Storage temperature / humidity range -20 ~ 40 ° C, relative humidity 85% or less with no condensation
Other LCD

backlight ON / OFF function

(ON Time: operation key operation or

measurement light 30 seconds)
Standard accessories White Calibration Plate CR-A43, cover CR-A72, tightening clamp CR-A73, AC Adapter AC-A17, 4 AAA batteries White Calibration Plate CR-A44, cover CR-A72, CR-tightening clamp A73, AC Adapter AC-A17, 4 AAA batteries

High Powerful Paper Testing Equipments Hardness For Residential Construction

About Haida
Haida products are widely used in paper products, packaging, ink printing, adhesive tapes, bags, footwear, leather products, environment, toys, baby products, hardware, electronic products, plastic products, rubber products and other industries, and are applicable to all scientific research units, quality inspection institutions and academic fields. Our products meet UL, ASTM, JIS, GB,SO, TAPPI, EN, DIN, BS and other domestic and international standards.
