Upholstered Furniture Ignition Resistance Tester With Stainless Steel Burner Tubes And Observation Window
Upholstered Furniture Ignition Resistance Tester With Stainless Steel Burner Tubes And Observation Window
Specifications
Brand Name :
HAIDA
Model Number :
6030-HD
Certification :
ISO,CE,
Place of Origin :
Guangdong, China (Mainland)
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram,In cash, escrow
Supply Ability :
300 Sets per Month Haida
Delivery Time :
20 days after order confirmed
Packaging Details :
Each set protected with resin fiber and PP film, then put into Strong wooden case with operation man
Gas Delivery :
Hose: 2.5–3mm length, Ø7±1mm inner diameter
Observation Window :
Tempered glass with SUS304 stainless steel frame
Ignition Method :
High-voltage electronic auto-ignition
Ignition System :
Stainless steel burner tubes (2 sets): Ø8±0.1mm (outer), Ø6.5±0.1mm (inner), 200±5mm length
Emission Purification 1 :
Spray system (water-filter interaction)
Emission Purification 2 :
Particulate filtration (eco-friendly filter media)
Emission Purification 3 :
Exhaust (high-power forced ventilation)
Description

Upholstered Furniture Ignition Resistance Tester

Description:

Upholstered Furniture Ignition Resistance Tester is evaluates ignition resistance of public-use mattresses, sofas, and other upholstered furniture. Simulates match-flame ignition to assess fire resistance of fabric covers, linings, and fillings.

Compliance Standards:

1.1 ISO 8191-2: Furniture — Assessment of the ignitability of upholstered furniture — Part 2: Ignition source match flame equivalent

1.2 ISO 8191-2 specifies test methods and evaluation criteria for assessing ignition resistance of upholstered furniture using a match-flame-equivalent ignition source.

Upholstered Furniture Ignition Resistance Tester With Stainless Steel Burner Tubes And Observation Window

Technical Parameters:

Model 6030-HD
Test Chamber Volume: 27m³ (3×3×3m); Double-layer stainless steel with 40mm thermal insulation; Ventilation system included
Ignition System Stainless steel burner tubes (2 sets): Ø8±0.1mm (outer), Ø6.5±0.1mm (inner), 200±5mm length
Gas Delivery Hose: 2.5–3mm length, Ø7±1mm inner diameter
Flow Control Flowmeter, fine-tuning valve, shutoff valve, regulator; Flow rate: 45±2 mL/min at 2.8kPa
Observation Window Tempered glass with SUS304 stainless steel frame
Ignition Method High-voltage electronic auto-ignition
Control System PLC-based microcomputer; Automated test timing/recording; User-friendly interface
Emission Purification Three-stage stainless steel (SUS304) scrubber tower (Ø800×3500mm):
• Spray system (water-filter interaction)
• Particulate filtration (eco-friendly filter media)
• Exhaust (high-power forced ventilation)

ABOUT HAIDA

Upholstered Furniture Ignition Resistance Tester With Stainless Steel Burner Tubes And Observation Window

Upholstered Furniture Ignition Resistance Tester With Stainless Steel Burner Tubes And Observation Window

Upholstered Furniture Ignition Resistance Tester With Stainless Steel Burner Tubes And Observation Window

Why choose us?

1.Design & Production : Solution Consultation for each order
Recommend the most cost -performance machine
Research & Develop the suitable one for Special- designed Model.
2.Shipping & Delivery: One-Stop Service
Production- Deliver to your door - Installation & Training- Technical Support
3.Warranty
1 year warranty with lifetime technology support
4.After-Sale Service
React within 2 Hours
Video inspection & on-site service combined

FAQ

Q: How about your warranty?

A: Generally, our warranty is one year. Within the warranty period, we can offer technique support and part parts change, if it's necessary, our engineers may go to your place for better service.

Q: What is the order process?

A: Get Inquiry - Send the Quotation - Confirm the requirements - Order confirming - Payment - production - testing and debugging- packing - Confirm with customer about the necessary documents- Arrangement the Delivery - Send the product out - Customer Receiving - After Service.

Q: Can we visit your factory before order?

A: Yes, we warmly welcome and sincerely invite you and your team to visit our factory, we will help to arrange hotel and pick up you from airport.

Q: Do you accept customization service?

A: Yes, of course, we can not only offer standard machines, but also customized machines according to your request. Don't hesitate to tell us your requirement, we will do our best to meet your needs.
