Cement Factory Dryer Supporting Reverse Air Bag Industrial Dust Collector For Sale
Cement Factory Dryer Supporting Reverse Air Bag Industrial Dust Collector For Sale
Cement Factory Dryer Supporting Reverse Air Bag Industrial Dust Collector For Sale
Cement Factory Dryer Supporting Reverse Air Bag Industrial Dust Collector For Sale
Cement Factory Dryer Supporting Reverse Air Bag Industrial Dust Collector For Sale
Cement Factory Dryer Supporting Reverse Air Bag Industrial Dust Collector For Sale
Specifications
Brand Name :
HeBei QiaoDa
Model Number :
custom
Certification :
YES
Place of Origin :
China
MOQ :
1
Price :
$3,000 - $50,000
Payment Terms :
T/T, MoneyGram
Supply Ability :
10-20 units per month
Delivery Time :
15-30 work days
Packaging Details :
Communicate with customers
Airflow :
5000m3/h
Condition :
New
Installation :
Floor/Ceiling
Warranty :
1 Year
Fan Power :
7.5-55 kw
Core Components :
Pump
Cleaning Way :
Dust removal by vibration
Graphic Customization :
Accepted
Customization :
accept
Oem :
Yes
Resistance :
<1000 pa
Gas Temperature :
Normal temperature
Filter Area :
220-10000m2
Shipping Type :
By land or sea
Dust Collection :
≤10mg/m³
Description

The principle and use of mechanical rotary reverse blower bag dust collector for cement factory

dryer can be elaborated as follows:The principle and use of mechanical rotary reverse blower

bag dust collector for cement factory dryer can be elaborated as follows:
During the operation of the mechanical rotary reverse air bag dust collector, the air flow rotates

in the lower cylinder section after the dust-bearing gas enters the dust collector along the

tangential direction from the air inlet. Under the action of centrifugal force and gravity, the dust

with large particle size is separated and moved down the wall of the cylinder into the ash hopper.

The finer dust rises with the air flow and is filtered through the trapezoidal (round or oval) filter bag

arranged in a radial shape, and the dust is blocked on the outside of the filter bag. The purified gas

passes through the filter bag and enters the clean gas chamber above the filter bag mouth and is

discharged by the outlet pipe.
Mechanical rotary reverse air bag dust collector is widely used in many industries, such as cement

industry: used for dust treatment of coal mill, powder mill, grate cooler and other equipment.

Steel industry: dust purification generated in the process of steel smelting, rolling, etc. Chemical

industry: dealing with all kinds of dust and particulate matter produced in the process of chemical production.

Model number Filter area(m2) Treated air volume

Bag length

(m)

Bag number

(PCS)

Dust removal efficiency

 resistance

Dimensions (diameter × height)

(mm)

 weight(kg)
specification

V

Meter per minute

 m3/h
ZC-144/3 A 340 1.0-1.5 20400-30600 3.0 144 ＞99 ＜120 ф3530×7145 8900
B 340 2.0-2.5 40800-51000 3.0 144 ф3530×7145 8900
ZC-144/4 A 450 1.0-1.5 27000-40500 4.0 144 ф3530×8145 11760
B 450 2.0-2.5 54000-67500 4.0 144 ф3530×8145 11760
ZC-144/5 A 569 1.0-1.5 34140-51210 5.0 144 ф3530×9145 14280
B 569 2.0-2.5 68280-85350 5.0 144 ф3530×9145 14280
ZC-144/4 A 760 1.0-1.5 45600-68400 4.0 240 ф4380×9060 16100
B 760 2.0-2.5 91200-114000 4.0 240 ф4380×9060 16100
ZC-144/5 A 950 1.0-1.5 57000-85500 5.0 240 ф4380×10370 18270
B 950 2.0-2.5 114000-142500 5.0 240 ф4380×10370 18270
ZC-144/6 A 1140 1.0-1.5 68400-102600 6.0 240 ф4380×11870 20039
B 1140 2.0-2.5 136800-171000 6.0 240 ф4380×11870 20039
