Item: Top Thermal Paper/AFB Adhesive/Glassine Liner

Key Features:

> Very good barcode printing performance
> Semi top coated protection layer, deep black color developing;
> Anti Freezing Adhesive, Low labeling temperature
> Suitable for frozen products label and logistic label in freezing temperature.

Facestock
Semi Top Coated Thermal Paper, A smooth white matte paper coated with a black imaging thermo sensitive coating.

Basis Weight: 70gsm± 10%
Caliper: 0.070mm ± 10%

Adhesive
AFB Model. Permanent, rubber based adhesive with anti freezing function.

Liner
A super calendared white glassine paper with excellent roll label converting properties.
Basis Weight: 60GSM Color: White, Yellow, Blue
Caliper: 0.050mm

Performance data

Viscosity: 15000-17000 180°Pealing Streagth: 17.3N

Innitial Tack: 12N or ball No 9 Hold Tack: More than 72 Hours

Minimum Labeling Temperature: -25℃
After Labeling 24Hous,Service Temperature Range: -50℃~55℃

Applications and use
This thermo sensitive product is designed for frozen food and other low temperature products, also for logistic label in freezing temperature.
Exposure to sunshine or above 50°C should be avoided. It’s not suitable for curve substrates.

Not recommend on the PVC substrate.

Conversion/printing
This product is suited for all the usual printing technologies. Due to the thermal sensibility, in the process material temperature should not more than 50℃. Solvent may cause damage to surface coating; care should be taken when using solvent based inks.

Excellent conversion characteristics in rotary and flat-bed, Suitable for high speed auto labeling.

Shelf life
One year when stored at 23 ±2°C at 50 ±5% RH.
