MAIN SPECIFICATION |
Engine | |
Engine Type: | Single cylinder,air-cooled,four stroke, |
Displacement (ml): | 223 |
Bore X Stroke(mm): | 65.5×66.2 |
Compression Ratio: | 9.25:1 |
Max. Power (kw/r/min) | 12/7500 |
Max. Torque (N.m/r/min): | 18/5500 |
Max. Speed (Km/h): | ≥85 |
Lubrication: | Pressure ,splash |
Clutch Type: | Multiplate wet clutch, Manual |
Ignition: | CDI |
Starting System: | Electric/Kick Start |
Transmission System: | Chain drive |
The left and right steering angle | left 39º right 40º |
CHASSIS | |
Front Brake: | disc/drum brake |
Rear Brake: | disc/drum brake |
Front Tire: | 3.50-17 |
Rear Tire: | 4.60-17 |
Battery: | 12V/7AH |
DIMENSIONS | |
L X W X H (mm): | 2000*800*850 |
Seat Height (mm): | 850 |
Wheelbase (mm): | 1340mm |
Min. Ground Clearance(mm): | 200 |
Max. Permissionable Weight (kg): | 165 |
Rider Capacity: | 2 Person |
Dry. Weigth (kg): | 145 |
Engine Oil (L): | 1L SAE15W/40 |
Fuel Tank Capacity (L): | 14 |
Roll angle (°) | 10° |
Our Dual Sport Motorcycle is carefully packaged and shipped to ensure its safe arrival to our customers. The packaging and shipping process is as follows:
FAQ:
Q: What configurations are available?
A: MP3, USB, Remote Controller, Alarm.
Q: Can I set my own colors?
A: Customed color and sticker design is accepted.
Q: What are the engine displacements?
A: The engine displacement options are YB110 or Z110 or C110 or YB115.
Q: What other accessories are available?
A: Rear rack or Small rear carrier or Tail box.
Q: What are the types of brakes?
A: Front disc brake or drum brake.
Q: What are the types of wheels?
A: Alloy wheel or spoke wheel.
