60km BIDI 10G SMF SFP Module 1270nm R1330nm Network Solution
60km BIDI 10G SMF SFP Module 1270nm R1330nm Network Solution
60km BIDI 10G SMF SFP Module 1270nm R1330nm Network Solution
60km BIDI 10G SMF SFP Module 1270nm R1330nm Network Solution
Specifications
Brand Name :
Toptrans
Model Number :
TOP-BIDI-XFP-ER+-60A
Certification :
Rohs
Place of Origin :
China
MOQ :
1
Price :
negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram,Paypal
Supply Ability :
20000pcs per month
Delivery Time :
3-4days
Packaging Details :
Anti-static package, standard packing
Data rate :
10G
Connector :
LC
Industrial Temperature :
0°Cto70°C
Form-Factor :
SFP
Distance :
60Km
power consumption :
＜1.8W
wavelength :
1270/1310nm
laser transmitter :
DFB
Description

1270nm/R1330nm Network Solution 60km Optical Transceiver SFP SMF Module

60Km Transceiver Network Solution Products Fetures:

● Hot pluggable

● Support 9.95Gb/sto11.1Gb/s bit rates

● Below<1.8w power consumption

● XFPMSA package with LC connector

● Digital Diagnostic Monitor Interface

● Very low EMI and excellent ESD protection

● Un-cooled 1270nmDFB laser and APD receiver

● +3.3V single power supply

● operating temperature range0°Cto70°C

● No reference clock requirement

APPLICATIONS

●10GBASE-BX10.3125Gb/s Ethernet

●10GBASE-BX9.953Gb/s Ethernet

●SONETOC-192 &SDH STM I-64.1

STANDARD

● XFPMSA Compliant

● SFF-8472reversion9.5compliant

● IEEE802.3-2005compliant

● TelcordiaGR-468-COREcompliant

● FCC47CFRPart15,Class B compliant

● FDA21CFR1040.10and1040.11,class1com-pliant

● RoHS compliant

Optical Module 60km BIDI Specification

Fibre type SMF

Standard Temperature

0°Cto+70°C

Power supply

4V

Distance

60Km

Form-Factor

SFP

Wavelength

 1270/1310 nm

Diagnostic

Yes

Optical Extinction Ratio

 3.5dB

Description

The XFP modules implement the 2-wire serial communication protocol as defined in the XFPMSA.

The serial ID information of the XFP modules and Digital Diagnostic Monitor parameters can be accessed through the I2C

interface at address A0handA2h. The memory is mapped in Table1. Detailed ID information(A0h) is listed in Ta-ble2. And the

DDM specification(A2h)is described in Table3. For more details of the memory map and byte definitions, please refer to the

SFF-8472(Rev9.3,Aug.2002), “Digital Diagnostic Monitoring Interface for Optical Transceivers”.

The DDM parameters have been internally calibrated.
