1310nm 10g Sfp+ Lr SMF S Class Low EMI IEC-60825 compliant For FTTO Network
1310nm 10g Sfp+ Lr SMF S Class Low EMI IEC-60825 compliant For FTTO Network
1310nm 10g Sfp+ Lr SMF S Class Low EMI IEC-60825 compliant For FTTO Network
1310nm 10g Sfp+ Lr SMF S Class Low EMI IEC-60825 compliant For FTTO Network
1310nm 10g Sfp+ Lr SMF S Class Low EMI IEC-60825 compliant For FTTO Network
1310nm 10g Sfp+ Lr SMF S Class Low EMI IEC-60825 compliant For FTTO Network
1310nm 10g Sfp+ Lr SMF S Class Low EMI IEC-60825 compliant For FTTO Network
1310nm 10g Sfp+ Lr SMF S Class Low EMI IEC-60825 compliant For FTTO Network
Specifications
Brand Name :
Mray
Model Number :
SFP-10G-LR
Certification :
CE, FCC, RoHs, ISO9001
Place of Origin :
Shenzhen, China
MOQ :
1 piece
Price :
Negotiable
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
10000pcs/day
Delivery Time :
1~2 days for samples
Packaging Details :
10pcs/plastic try, 500pcs per standard export carton
Product name :
10GBASE-LR SFP+ SMF 1310nm 10km Fiber Optic Transceiver Module
Rate :
10G
Distance :
10km
Fiber type :
SMF
Power Supply :
+3.3V
Warranty :
3 Years
Application :
FTTH FTTB FTTO Network
Operating temperature :
0~70 °C
Description

10G BASE LR 1310nm 10Km SFP+ Transceiver Module for SMF S-CLASS SFP-10G-LR-S

Description

Miray SFP+ transceiver supports up to 10km link lengths over LC duplex SMF fiber. Digital diagnostics monitoring is available via a 2-wire serial interface, as specified in SFF-8472. Each SFP+ transceiver module is individually tested to be used on a series of Cisco switches, routers, servers, network interface card (NICs) etc. Featuring low power consumption, high speed, this 10G SFP+ transceiver is ideal for data center, enterprise wiring closet, service provider transport application, Radio & Baseband Unit, etc.

Features

  • SFP+ package with LC connector
  • 1310nm DFB Laser and PIN photo detector
  • Up to 10km transmission on SMF
  • Power dissipation < 1W
  • LVPECL compatible data input/output interface
  • Low EMI and excellent ESD protection
  • laser safety standard IEC-60825 compliant
  • Compatible with RoHS
  • Compatible with SFF8472

Application

  • 10GBASE-SR,LRM,LR,ER,ZR at 10.31/11.3Gbps

  • SDH/SONET

  • OTN G.709/G.959.1

  • 10GBASE-LW/EW at 9.95Gbps

  • 8G/10G Fibre Channel

  • CPRI options 7/8

  • Other optical links

Absolute Maximum Ratings

Parameter

Symbol

Unit

Min

Max

Storage Temperature Range

Ts

oC

-40

85

Relative Humidity

RH

%

0

95

Maximum Supply Voltage

Vcc3

V

-0.5

4.0

Optical Parameters(TOP = -40 to 85°C, VCC = 3.135 to 3.465 Volts)

Parameter

Symbol

Min

Typ

Max

Note

Unit

Optical Transmitter Characteristics

Nominal Wavelength

λ

1310

nm

Optical Output Power

Pav

-6

2

dBm

Extinction Ratio

ER

3.5

dB

Average Launch Power of OFF Transmitter

POFF

-35

dBm

Relative Intensity Noise

RIN

-128

dB/Hz

Optical Receiver Characteristics

Center Wavelength

λC

1260

1620

nm

Receiver Sensitivity@10.3Gb/s

RSENSE

-14.4

1

dBm

Receiver Overload

0.5

dBm

Optical Return Loss

27

-

dB

LOS Assert

LOSA

-30

dBm

LOS De-Assert LOS

LOSD

-17

dBm

LOS Hysteresis

0.5

dB

Dimension

1310nm 10g Sfp+ Lr SMF S Class Low EMI IEC-60825 compliant For FTTO Network

Product Packing

1310nm 10g Sfp+ Lr SMF S Class Low EMI IEC-60825 compliant For FTTO Network

Compatibility Test

1310nm 10g Sfp+ Lr SMF S Class Low EMI IEC-60825 compliant For FTTO Network

1310nm 10g Sfp+ Lr SMF S Class Low EMI IEC-60825 compliant For FTTO Network

Compatible Brands

1310nm 10g Sfp+ Lr SMF S Class Low EMI IEC-60825 compliant For FTTO Network

Production Flow

1310nm 10g Sfp+ Lr SMF S Class Low EMI IEC-60825 compliant For FTTO Network

For more details, welcome to inquire us freely.
