Generic 100g Qsfp28 Aoc Displayport Cable 2m Single MPO Connector
Generic 100g Qsfp28 Aoc Displayport Cable 2m Single MPO Connector
Generic 100g Qsfp28 Aoc Displayport Cable 2m Single MPO Connector
Generic 100g Qsfp28 Aoc Displayport Cable 2m Single MPO Connector
Generic 100g Qsfp28 Aoc Displayport Cable 2m Single MPO Connector
Generic 100g Qsfp28 Aoc Displayport Cable 2m Single MPO Connector
Specifications
Brand Name :
Mray
Model Number :
QSFP28-100G-AOC2M
Certification :
CE, FCC, RoHs, ISO9001
Place of Origin :
Shenzhen, China
MOQ :
1 piece
Price :
Negotiable
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
10000pcs/week
Delivery Time :
1~2 days for samples
Packaging Details :
10pcs/plastic try, 500pcs per standard export carton
Product name :
QSFP28-100G-AOC-2M Compatible 100G QSFP28
Data Rate :
100Gbps
Distance :
2M
Application :
Data Center
Fiber Type :
OM3/OM4 MMF Cable
Operating temperature :
0°C to 70°C
Compatible :
Cisco, Huawei, HP, Juniper
Warranty :
3 Years
Description

Generic QSFP28-100G-AOC-2M Compatible 100G QSFP28 Active Optical Cable AOC

Description

Miray’s QSFP28-100G-AOC is a high-quality Generic QSFP28-100G-AOC-2M Compatible 100G QSFP28 Parallel AOC (Active Optical Cable). A cost-effective solution that provides high bandwidth and transmission rates over short distances. 100Gb/s QSFP28 AOC is a high data rate parallel active optical cable (AOC). 4 independent data transmission channels and 4 data receiving channels. Each channel is capable of 25Gb/s operation. Each AOC active fiber optic cable is 100% optically inspected and tested for compatability before shipping.

Features

  • 4 channels full-duplex transceiver modules
  • Transmission data rate up to 25Gbps per channel
  • Support 40GE and 56G FDR data rate
  • 4 channels 850nm VCSEL array
  • 4 channels PIN photo detector array
  • Internal CDR circuits on both receiver and transmitter channels
  • Support CDR bypass
  • Low power consumption <2.5W
  • Hot Pluggable QSFP form factor
  • Maximum link length of 70m on OM3 Multimode Fiber (MMF)and 100m on OM4 MMF
  • Single MPO connector receptacle
  • Operating case temperature 0°C to +70°C
  • 3.3V power supply voltage
  • RoHS 6 compliant(lead free)

Recommended Operating Environment

Parameter

Conditions

Min

Typ.

Max

Units

Data rate per lane

8B/10BCoding, 64B/66B Coding

1

26

Gbps

3.3V Supply Voltage

3.13

3.3

3.47

V

Power supply noise including ripples

1kHz to frequency of operation mersured at VCC_HOST

50

mVpp

Case temperature

0

35

70

℃

Optical Characteristics

Parameter

Symbol

Min

Typical

Max

Unit

Notes

Transmitter

Centre Wavelength

λc

840

850

860

nm

-

RMS spectral width

∆λ

-

-

0.6

nm

-

Average launch power, each lane

Pout

-8.4

-

2.4

dBm

-

Optical Modulation Amplitude (OMA),each lane

OMA

-6.4

3

dBm

-

Transmitter and dispersion eye closure(TDEC),each lane

TDEC

4.3

dB

Extinction Ratio

ER

3

-

-

dB

-

Average launch power of OFF transmitter, each lane

-30

dB

-

Eye Mask coordinates: X1, X2, X3, Y1, Y2, Y3

SPECIFICATION VALUES

{0.3,0.38,0.45,0.35,0.41.0.5}

Hit Ratio = 5x10-5

Receiver

Centre Wavelength

λc

840

850

860

nm

-

Stressed receiver sensitivity in OMA

-5.2

dBm

1

Maximum Average power at receiver , each lane

2.4

dBm

-

Minimum Average power at receiver , each lane

-10.3

dBm

Receiver Reflectance

-12

dB

-

Ordering Information

Part No. Product Type Rate Media Type Wavelength Reach Commercial Temp. Industrial Temp.
QSFP28-100G-AOC1M QSFP28 AOC 40G MM 850nm 1m 0~70℃ -40~85℃
QSFP28-100G-AOC2M QSFP28 AOC 40G MM 850nm 2m 0~70℃ -40~85℃
QSFP28-100G-AOC3M QSFP28 AOC 40G MM 850nm 3m 0~70℃ -40~85℃
QSFP28-100G-AOC5M QSFP28 AOC 40G MM 850nm 5m 0~70℃ -40~85℃
QSFP28-100G-AOC7M QSFP28 AOC 40G MM 850nm 7m 0~70℃ -40~85℃
QSFP28-100G-AOC10M QSFP28 AOC 40G MM 850nm 10m 0~70℃ -40~85℃
QSFP28-100G-AOC20M QSFP28 AOC 40G MM 850nm 20m 0~70℃ -40~85℃
QSFP28-100G-AOC30M QSFP28 AOC 40G MM 850nm 30m 0~70℃ -40~85℃

Application

Generic 100g Qsfp28 Aoc Displayport Cable 2m Single MPO Connector

Dimension

Generic 100g Qsfp28 Aoc Displayport Cable 2m Single MPO Connector

Product Packing

Generic 100g Qsfp28 Aoc Displayport Cable 2m Single MPO Connector

Compatibility Test

Generic 100g Qsfp28 Aoc Displayport Cable 2m Single MPO Connector

Compatible Brands

Generic 100g Qsfp28 Aoc Displayport Cable 2m Single MPO Connector

Reliablity Assurance

Generic 100g Qsfp28 Aoc Displayport Cable 2m Single MPO Connector

Generic 100g Qsfp28 Aoc Displayport Cable 2m Single MPO Connector
Generic 100g Qsfp28 Aoc Displayport Cable 2m Single MPO Connector

For more details, welcome to inquire us freely.
