State-of-the-Art CNC Flame and Plasma Pipe Cutting Machine for Pipeline Construction
The cutting machine will creep on pipes and send the high- precision location information to control system, and then follow the cutting line immediately. This cutting method is totally different from the traditional large scale pipe intersection line cutting method.

The unique portable & bevel profile cutting machine can be used in factory and on-site, almost suitable for all pipes with
different sizes. Its cutting accuracy could reach 1mm with build-in program & parameterized input interface. The whole machine is delicate and can be operated, delivered & stored easily. Additionally, the program can be updated.

No need for importing CAD, parameterized input interface, one person could operate it, complete model bases, providing model custom service.
State-of-the-Art CNC Flame and Plasma Pipe Cutting Machine for Pipeline Construction
State-of-the-Art CNC Flame and Plasma Pipe Cutting Machine for Pipeline Construction

Main Frame

1- Lines box2- Sensor box
3- Machine base part
4- Single axis arm
5- Torch clamp
State-of-the-Art CNC Flame and Plasma Pipe Cutting Machine for Pipeline Construction

Control box

1- Protective mask
2- Control box
3- Control panel
4- Air filter
State-of-the-Art CNC Flame and Plasma Pipe Cutting Machine for Pipeline Construction

Anti-skid Chain

1- Anti-skid chain
2- Chain union
3- Flat pin
State-of-the-Art CNC Flame and Plasma Pipe Cutting Machine for Pipeline Construction

Orbital Track

Right to left:
STG1,STG2,STG3,STG4,STG5,STG6
State-of-the-Art CNC Flame and Plasma Pipe Cutting Machine for Pipeline Construction

Claw Connector

1- Hole
2- Hook
3- Long hexagonal bolt
Product Parameter
Table 1. Equipment Lectotype
Type
Model
Software
Pipe Diameter
Horizontal Adjustment
Simplified Machine
TP1-JH
01/07
<320mm
200mm
Basic Machine
TP1-JB
<680mm
400mm
Standard Machine
TP1-BZ
<1020mm
600mm
Classic R Machine
TP1-R80B
01/02/03/05/06/07/08
<1800mm
800mm
Classic X Machine
TP1-X80B
01/02/03/05/06/07/08/09/10/11/12
<3000mm
800mm
Tie-In Machine
TP1-PSK
07
320-1420mm
200mm
State-of-the-Art CNC Flame and Plasma Pipe Cutting Machine for Pipeline Construction
Orbital Track
Table 2.Cutting Machine Orbital Details
NO.
Model
Length/m
Adjustable range/m
Claw with contributory posterior adjustment range
1
STG1
0.98
0.54~0.71
0.68~0.86
2
STG2
1.23
0.79~0.96
0.93~1.14
3
STG3
1.38
0.91~1.16
1.06~1.30
4
STG4
1.72
1.16~1.45
1.30~1.60
5
STG5
1.90
1.46~1.63
1.60~1.81
6
STG6
2.50
2.06~2.23
2.20~2.41
Table 3.Orbit Matching Option
No.
Pipe OD/mm
Suggested Orbits
1
320-400
STG3
2
400-495
STG4
3
495-550
STG5
4
550-680
STG1+ STG 3
5
630-770
STG1+ STG 4
6
730-830
STG1+ STG 5
7
810-915
STG2+ STG 5
8
915-1020
STG1+ STG 6
9
1000-1100
STG2+ STG 6
10
1040-1160
STG3+ STG 6
11
1120-1250
STG4+ STG 6
12
1219-1310
STG5+ STG 6
13
1270-1480
STG3+ STG 4+ STG 5
14
1410-1500
STG6+ STG 6
15
1450-1595
STG2+ STG 5+ STG 6
16
1520-1675
STG6+ STG 6+ STG 1
Table 4.Control Box
Display
111mm×62mmLCD
Button No.
20pcs
Power-off Protection
10years
Working Temperature
-10℃～ +55℃
Voltage
220V AC
Power
600 W
Main kit Weight
5KG
Size
400（L）×200（W）×200（H）mm

Product Advantages

1, Theoretical innovation
The sensor technology is used to realize the trajectory control. The intersecting line cutting machine climbs on the pipe, sends the high-precision real-time position information to the control system, and then follows the cutting curve in a very small time.This control method is completely different from the traditional bench pipe intersecting line cutting.

2, Structural innovation
It is the first time to put forward a complete solution of on-site cutting of pipeline intersecting line. By using the crawling
cutting method around the pipe, the volume and weight can be significantly reduced, which is easy to carry to the site, does not occupy the resources of the workshop, and can realize the flexible production line layout.
