CE FDA TLC5000 Portable Patient Monitor 12 channels ECG Holter Machine for Family
CE FDA TLC5000 Portable Patient Monitor 12 channels ECG Holter Machine for Family
CE FDA TLC5000 Portable Patient Monitor 12 channels ECG Holter Machine for Family
CE FDA TLC5000 Portable Patient Monitor 12 channels ECG Holter Machine for Family
CE FDA TLC5000 Portable Patient Monitor 12 channels ECG Holter Machine for Family
CE FDA TLC5000 Portable Patient Monitor 12 channels ECG Holter Machine for Family
CE FDA TLC5000 Portable Patient Monitor 12 channels ECG Holter Machine for Family
CE FDA TLC5000 Portable Patient Monitor 12 channels ECG Holter Machine for Family
CE FDA TLC5000 Portable Patient Monitor 12 channels ECG Holter Machine for Family
CE FDA TLC5000 Portable Patient Monitor 12 channels ECG Holter Machine for Family
Specifications
Brand Name :
CONTEC
Model Number :
TLC5000
Certification :
CE
Place of Origin :
Guangdong, China
MOQ :
1pc
Price :
USD495~550/pc
Payment Terms :
Western Union, MoneyGram, T/T, Paypal
Supply Ability :
10000pcs per week
Delivery Time :
3~5 working days
Packaging Details :
Color box
Type :
Dynamic ECG
Screen :
OLED Screen
Resolution :
160*128
Channels :
12 Channels
Description

CE FDA TLC5000 Portable Patient Monitor 12 channels ECG Holter Machine for Family

Model Number: TLC5000

Introduction:


Dynamic ECG Systems TLC5000 contain recorder & analysis software.


Recorder is an easy- to -use unit, which collects 12-lead ECG waveform synchronously and records continuously for 24 hours. In addition, it also reviews ECG waveform.


It is easy for you to use analysis software which plays back ECG waveform stored in ambulatory recorder and achieves kinds of analysis functions, such as arrhythmia, HRVA, QTDA, TWA, etc.

Quick Details:

1.Dynamic ECG Systems TLC5000
2.2 AA size batteries
3.24 hours monitoring

4.12 leads

5. 12 channels

CE FDA TLC5000 Portable Patient Monitor 12 channels ECG Holter Machine for Family

CE FDA TLC5000 Portable Patient Monitor 12 channels ECG Holter Machine for Family

CE FDA TLC5000 Portable Patient Monitor 12 channels ECG Holter Machine for Family

Technical Parameters

Number of channels 12 channels
Sampling rate 10000Hz
Sampling accuracy 12bit
Recording time 24 h
Power 2 batteries in size 5
Interface USB2.0
Scale voltage 1mV±5%
Standard Sensitivity 10mm/mV±5%
Noise level ≤30μV
CMRR ≥60dB
Feathers of low frequency Time constant>3.2s
Scan speed 25mm/s±5%
Enduring polarization voltage ±300mV
Least measure signal 50 µV p-p
Product safety type Type B (Internally powered)
Size 111mm(L)*60mm(W)*25mm(H)
Net Weight

102g (Without battery)

Major Features:


1. With advanced design and technology, the recorder can work stably, dependable and durable.


2. Be provided with the capability of anti-jamming and shock-pro.


3. Small volume with OLED screen. The resolution is 160*128.


4. Be provided with functions of waveform preview, record review and event marking.


5. Accurate record of the start time of the data sampled owing to the real time clock of itself.


6. Avoid damage owing to the repeating inserting and pulling out by using the inbuilt TF card to storage the data.


7. The maximum capability can be 2GB, so the original data can be saved perfectly by no compression.


8. The average review time of single case can be less than 40 seconds by using interface of USB 2.0.


9. Record waveform details inextenso by the design of high precision and sampling frequency.


10. Record the state of pacemaker exactly by higher sampling frequency.


11. International standard of 12 leads. Record 24-hour DECG with the same standard of the ECG.


12. 12 channels

Sell in Standard:

USB data line

A CD (analysis software)

ECG Leads

An User manual

Carry bag

Electrode patch

Dongle

CE FDA TLC5000 Portable Patient Monitor 12 channels ECG Holter Machine for Family
