ODM Temperature Resistant SIO2 40/60 Quartz Glass Sheet
ODM Temperature Resistant SIO2 40/60 Quartz Glass Sheet
ODM Temperature Resistant SIO2 40/60 Quartz Glass Sheet
ODM Temperature Resistant SIO2 40/60 Quartz Glass Sheet
Specifications
Brand Name :
shengfan
Model Number :
QP-1
Certification :
ISO9001
Place of Origin :
China
MOQ :
10 pieces
Price :
Negotiable
Supply Ability :
100,000 pieces/month
Delivery Time :
5-15 work days
Packaging Details :
plastic bubble/ polystyrene foam sheet/ carton/ wooden pallet
Product Name :
Precision Glass Machining
Material :
SIO2
Hardness :
morse 6.5
Working temperature :
1200℃
Surface quality :
20/40 or 40/60
Dieletric strength :
250～400Kv/cm
Light Transmittance :
>92%
Finish :
polished
Oem/odm :
customizable,Accept,OEM and ODM
Description

Customizable Precision Glass Machining >92% Light TransmittanceFused Glass Plates Ground Polished Heat Resistant

Product description:

Quartz glass disc is made of fused quartz in special industrial technology glass which is a very good base material.

Quartz glass has excellent physical and chemical properties:high purity, strong transmission, strict size control, low OH content and so on. The deep processing would be done according to client's requirements, like neat cutting, punching,finish milling, fire polish, bending, sealing, polished and so on.

Application of quartz plate:

Military industrial complex, machinery, metallurgy, printing and dyeing, optical instruments, high temperature sight glasses, fire hole industries such as high temperature and other industries, electric light source equipment, Labortory instrument, chemical apparatus.

Fused Silica Capillary Tubing Description:

Density 2.2x103 kg/m3 Hardness 5.5 - 6.5 Mohs' Scale 570 KHN 100
Design Tensile Strength 4.8x107 Pa (N/m2) (7000 psi) Design Compressive Strength Greater than 1.1 x l09 Pa (160,000 psi)SMD 5730
Bulk Modulus 3.7x1010 Pa (5.3x106 psi) Rigidity Modulus 3.1x1010 Pa (4.5x106 psi)
Softening Point 1730°C Annealing Point 1215°C

JGS1(ZS-1) JGS2(ZS-2) JGS3(HS)
Spectral characteristics 180-2500nm 200-2500nm 260-3500nm
The average transmittance 90% 85% 85%
Bubble class 0 2 2
Birefringence 1-2 1-2 1-2
Grain structure 1 2 2
Fringe 1-2 2 2
Uniformity 1-2 2 2
Fluorescence 1 2 2
Radiation Performance Does not change clolor Sight discoloration Change color
Quartz Characteristic
SIO2 99.99%
Density 2.2(g/cm3)
Degree of the hardness moh’ scale 6.6
Melting point 1732℃
Working temperature 1100℃
Max temperature can reach in a short time 1450℃
Acid tolerance 30 times than ceramic,150 times than stainless
Visible light transmittance Above 93%
UV spectral region transmittance 80%
Resistance value 10000 times than ordinary glass
Annealing point 1180℃
Softening point 1630℃
Strain point 1100℃

ODM Temperature Resistant SIO2 40/60 Quartz Glass Sheet

ODM Temperature Resistant SIO2 40/60 Quartz Glass Sheet

ODM Temperature Resistant SIO2 40/60 Quartz Glass Sheet

Company profile:

Lianyungang Shengfan Quartz Product Factory is a professional manufacture specialized in research and development of quartz plate,quartz tube,quartz flange,quartz ring,cuvette and quartz instrument. The company is located in China Crystal Capital - Donghai City, Jiangsu Prov., China.

With the philosophy of Technology Orientation, Quality First,Integrity and Responsibility,Sustainable Operation, the company dedicates to establish an international enterprise with standard and sustainable operation capability.

ODM Temperature Resistant SIO2 40/60 Quartz Glass Sheet

LIANGYUNGANG SHENGFAN QUARTZ PRODUCTS CO. LTD

TEL : 00860518878938285
Mobile : 008619901512909
Wechat : shengfanquartz
E-mail : shengfanquartz@163.com
Website : https://shengfanquartz.1688.com
Address : NO.169 Mingzhu Rd, Economic Development Zone, Donghai country,Lianyungang city, Jiangsu prov.,China.
