Solar Panel Inspection Machine 450W 550W High Efficiency Solar Cell Testing Machine

Overview

0.8 - 1.2Mpa Visual Inspection Machine Semi Auto Operation Solar Cell Testing Machine

The equipment is specially used in the filtration of solar energy mono-crystalline silicon and the poly-crystalline silicon cell pieces. Through stimulates the solar spectrum lamp-house, carries on the testing and surveys to the cell module related electrical parameter, according to the measurement result classifies the cell piece.

It has unique apparatus of modifying, to input the compensate parameter, it will carries on automatically
/ manual temperature compensation and compensate with the light intensity, and automatically
measures and modifies the temperature. Based on the Windows operation surface, and humanized-design testing software, it records and displays test curve (I-V curve, P curve) and the test parameter (Voc, Isc, Pm, Im, FF, EFF), the test of sequence number is automatically produced and preserved to the assigned folder.

Features

1. The entire stainless steel chamber avoids welding deformation of the stainless steel and the general steel. The high quality welding of argon reduces vacuum system leaking rate. The use of calibration thermo-couple gauge made no false vacuum reading.

2. The strengthened design and the high smoothness avoid the laminated fragment and shift. Hot working design of the computer auxiliary reduces the temperature unevenness on controlling of the false muti-spots. The close heat conduction coupling avoids temperature fluctuation on the laminated process.

3. Optimized PID control improves the accuracy of temperature control. The fabric strengthened offset plate extends the using time and reduces the working costs. The program-controlled design levels up the flexibility.

Parameters

Application

The entire stainless steel chamber avoids welding deformation of the stainless steel and the general steel.
The high quality welding of argon reduces vacuum system leaking rate. Hot working design of the computer auxiliary reduces the temperature unevenness on controlling of the false muti-spots. The close heat conduction coupling avoids temperature fluctuation on the laminated process

Solar Panel:

Higher solar module efficiency lower solar system cost per watt

New Design, 5BB Full Cell, Monocrystallion silicion Higher cells efficiency, better light converting rate

Solar Panel Dimension: 1640*992*35mm, high winds (2400PA) and snow loads (5400PA)

Maximum Power: 335W, voltage at Pmax: 34.00V, current at Pmax: 9.85A

Warranty: 25-year transferable power output warranty
