High Flow Steel Hydraulic Quick Coupler Up To 5500 Psi St Series Nipple
High Flow Steel Hydraulic Quick Coupler Up To 5500 Psi St Series Nipple
High Flow Steel Hydraulic Quick Coupler Up To 5500 Psi St Series Nipple
High Flow Steel Hydraulic Quick Coupler Up To 5500 Psi St Series Nipple
Specifications
Brand Name :
QPE
Model Number :
ST PF SERIES
Certification :
ISO9000
Place of Origin :
CHINA
MOQ :
300
Price :
Negotiable
Supply Ability :
90,000 pcs/week, according the capacity of the assembly workshop
Delivery Time :
Within 30 days or as per customers' requirement
Packaging Details :
Standard exporting package or as per customers' requests
Material : :
Carbon steel
Size : :
1/8"-1 1/2"
Thread : :
BSPP, BSPT, NPT
Connection : :
Locking balls
Standard : :
Compatible with PARKER ST Series, HANSEN ST Series, FOSTER FST Series
Media :
Hydrulic
Temperature Range :
-25°C to +125°C
APPLICATION :
Hydraulic, high flow
Description

Steel Straight Through Hydraulic Quick Connect nipples Female Thread ST Series

Feature:

1. Connexion by pushing back sleeve

2. Disconnexion by pulling back the female sleeve

3. Connecxion under pressure not allowed

4. Disconnexion under pressure not allowed

5. Interchangeability PARKER ST series

Technical Specification

1. Meterial: Carbon steel

2. NBR Backup ring in PTFE

3. Temperature Range(-25°C to +125°C)

4. According t ISO 7241-2

Fidels of application

Part No. ISO Thread

Size

(inch)

Working Pressure

(PSI)

Rated Flow

(L/min)

Temperature Range

(-25°C to +125°C)
ST -01 DN3 BSPT 1/8 BSPP1/8 NPT1/4 1/8 2500 3
ST -02 DN6.3 BSPT 1/4 BSPP1/4 NPT1/4 1/4 5200 6
ST -03 DN10 BSPT 3/8 BSPP3/8 NPT3/8 3/8 2700 12
ST -04 DN12.5 BSPT 1/2 BSPP 1/2 NPT1/2 1/2 2200 12
ST -06 DN20 BSPT 3/4 BSPP 3/4 NPT3/4 3/4 1700 28
ST -08 DN25 BSPT 1 BSPP 1 NPT1 1 1200 50
ST -10 DN25 BSPT 1 1/4 BSPP 1 1/4 NPT1 /4 1 1/4 1700 76
ST -10 DN25 BSPT 1 1/2 BSPP 1 1/2 NPT1 /2 1 1/2 1400 100
