Din Rail Electrical Terminal Block Modular Screw Connection Power Distribution Universal
Din Rail Electrical Terminal Block Modular Screw Connection Power Distribution Universal
Din Rail Electrical Terminal Block Modular Screw Connection Power Distribution Universal
Din Rail Electrical Terminal Block Modular Screw Connection Power Distribution Universal
Specifications
Place of Origin :
CHINA
Brand Name :
VSELE
Delivery Time :
5~30days According to the order quantity
Payment Terms :
T/T, Paypal, Western union, L/C etc.
Name :
Modular Distribution Blocks
Material :
Flame resistant Nylon PA66, brass conductor
Color :
Blue and Gray
Connection method :
Screw connection
Rated Voltage/Current :
500V/125A
Mounting Type :
DIN Rail NS 35
MOQ :
100pcs
Price :
0.1-10
Supply Ability :
1000pcs per day
Description

Modular Distribution Blocks

● Connection with or without ferrules
● Supplied with insulated back plate and transparent protective front cover, self-extinguishing
● Mounting methods:
1. Fix on din-rail
2. On plate with 2 screws
● When installing under a front plate, a blanking plate can be clipped onto the front plate
● Insulation protection each bar
● Each bar can be labelled using cab 3TM
● Conform to standard EN60947-1
● ICC:20kA peak

FQA

Q: Are you manufacturer or trade company?

A: We are manufacturer and specialized in terminal block
Q: Do you have E- catalogue? Can you send me the catalogue to have a check of all your products?

A: Yes , We have.Please contact us on line or send an Email to sending the catalogue.

Q: Can you provide samples ? Are the samples free ?

A: Yes,we can provide free samples if quantity not too much but delivery fee need pay collect.

Item No . Bus Bar Spec. No . Of
Bus Bar		 Conductors
with starfix
ferrules
X-section
(mm2)		 Cond. W/
out ferr.
X-section
(mm2)		 Dimensions
(L×W×H)
(mm)
VVC-207 5×φ5.3mm
2×φ7.5mm		 2 1.5 to 6
6 to 16		 2.5 to 6
10 to 25		 65×42×50
VVC-211 7×φ5.3mm
2×φ7.5mm
2×φ9mm		 2 1.5 to 6
6 to 16
10 to 16		 2.5 to 6
10 to 25
10 to 35		 100×42×50
VVC-215 11×φ5.3mm
2×φ7.5mm
2×φ9mm		 2 1.5 to 6
6 to 16
10 to 16		 2.5 to 6
10 to 25
10 to 35		 135×42×50
VVC-407 5×φ5.3mm
2×φ7.5mm		 4 1.5 to 6
6 to 16		 2.5 to 6
10 to 25		 65×85×50
VVC-411 7×φ5.3mm
2×φ7.5mm
2×φ9mm		 4 1.5 to 6
6 to 16
10 to 16		 2.5 to 6
10 to 25
10 to 35		 100×88×50
VVC-415 11×φ5.3mm
2×φ7.5mm
2×φ9mm		 4 1.5 to 6
6 to 16
10 to 16		 2.5 to 6
10 to 25
10 to 35		 135×85×50
