PP Female Pipe and Fittings Compression Fitting for Irrigation Made of 100% Material
PP Female Pipe and Fittings Compression Fitting for Irrigation Made of 100% Material
PP Female Pipe and Fittings Compression Fitting for Irrigation Made of 100% Material
PP Female Pipe and Fittings Compression Fitting for Irrigation Made of 100% Material
PP Female Pipe and Fittings Compression Fitting for Irrigation Made of 100% Material
PP Female Pipe and Fittings Compression Fitting for Irrigation Made of 100% Material
PP Female Pipe and Fittings Compression Fitting for Irrigation Made of 100% Material
PP Female Pipe and Fittings Compression Fitting for Irrigation Made of 100% Material
PP Female Pipe and Fittings Compression Fitting for Irrigation Made of 100% Material
PP Female Pipe and Fittings Compression Fitting for Irrigation Made of 100% Material
PP Female Pipe and Fittings Compression Fitting for Irrigation Made of 100% Material
PP Female Pipe and Fittings Compression Fitting for Irrigation Made of 100% Material
Specifications
Model NO. :
QX
Technics :
Injection
Certification :
DIN, BS
Color :
Deep Blue, Light Blue, Black
Material Like :
100% New Material
Size :
Complete Size
Feature :
with 201 Oring, Color Light
Package :
Standard and Good Package
Transport Package :
Plastic Bag, Export Cartons
Specification :
16mm to 110mm (1/2" to 4" )
Trademark :
QX
Origin :
China(Mainland)
HS Code :
39174000
Supply Ability :
50000 Piece /Month
Connection :
Female
Shape :
Equal
Head Code :
Round
Angle :
45deg, 90deg
Wall Thickness :
Pn10, Pn16
Material :
PP
Samples :
US$ 0/Piece 1 Piece(Min.Order) | Request Sample
Customization :
Available | Customized Request
MOQ :
1pc
Packaging Details :
Customized
Delivery Time :
5-8 days
Payment Terms :
L/C,T/T
Description
Good Price PP Female Pipe and Fittings Compression Fitting for Irrigation


1. PP Compression Fittings Description
Item Name PP compression fitting
Material PP
Standard DIN
Pressure PN10, PN16

Temperature		 Normal Temperature
Color Deep Blue, Light Blue, Black
Packing Carton, Polybag, Color Box or Customized
Size 20-110mm
Delivery port Ningbo by sea

PP Female Pipe and Fittings Compression Fitting for Irrigation Made of 100% Material
NO. PART MATERIAL
1 Body Heterophasic block polypropylene co-polymer(PP-B) of exceptional mechanical properties even at high temperature.
2 Nut
Polypropylene with dye master of high stability to UV rays andsolidity to heat( S grade according to standard DIN54004)
3 Clinching ring Polyacetal resin(POM)with high mechanical resistance
4 Blocking bush
Polypropylene
5 O-ring Special elastomeric acrylonitrile rubber(EPDM) for alimentary use

2. PP Compression Fittings Parameters PN16
Name Model Size
Tee QX81 16mm, 25mm, 32mm, 40mm, 50mm, 63mm, 75mm, 90mm, 110mm
Coupling QX82 16mm, 25mm, 32mm, 40mm, 50mm, 63mm, 75mm, 90mm, 110mm
Elbow QX83 16mm, 25mm, 32mm, 40mm, 50mm, 63mm, 75mm, 90mm, 110mm
End cap QX84 16mm, 25mm, 32mm, 40mm, 50mm, 63mm, 75mm, 90mm, 110mm
Male Adapter QX85 16mmx1/2"; 20mmx1/2", 20mmx 3/4", 25mmx1/2", 25mmx3/4", 25mmx1", 32mmx1/2", 32mmx3/4", 32mmx1", 40mmx1", 40x 1 1/4", 50mmx3/4", 50mmx1", 50mmx 1 1/4";50mm x 1 1/2", 63mmx3/4", 63mmx1", 63mmx 1 1/2", 63mmx2", 75mmx2", 75mmx2 1/2"; 90mmx 1 1/2", 90mmx2", 90mmx 2 1/2", 90mm x 3"; 110mm x3", 110mmx4"
Female Adapter QX86 16mmx1/2"; 20mmx 1/2", 25mmx1/2", 25mmx 3/4", 32mmx3/4", 32mmx1", 40mmx 1 1/4", 50mm x 1 1/2", 63mmx2", 75mmx 2 1/2", 90mmx3", 110mmx4"
Reducing Tee QX87 20mmx1/2", 25mmx 3/4", 25x1/2", 25mmx3/4", 25mmx1", 32mmx3/4", 32mmx1", 40mmx1", 40mmx 1 1/4", 50mmx 1 1/2", 63mm x 1 1/2", 63mmx2", 75mm x 2 1/2", 90mmx3", 110mmx4"
Reducing Coupling QX88 20mmx16mm, 25mmx20mm, 32mmx20mm, 32mmx25mm, 40mmx25mm, 40mmx32mm, 50mmx32mm, 50mmx40mm, 63mmx40mm, 63mmx50mm
Female Tee QX89 16mmx1/2", 20mmx1/2", 25mmx1/2", 25mmx3/4", 32mmx3/4", 32mmx1", 40mmx 1 1/4", 50mmx 1 1/4", 50mmx 1 1/2", 63mm x 1 1/2", 63mmx2", 90mmx 2 1/2", 90mmx3"
MALE TEE QX90 16mmx 1/2", 20mmx1/2", 20mmx 3/4", 25mmx1/2", 25mmx3/4", 25mmx1", 32mmx1/2", 32mmx3/4", 32mmx1", 40mmx 1 1/4"; 50mmx 1 1/2", 63mmx2"
Female Elbow QX91 16mmx1/2"; 20mmx 1/2", 25mmx1/2", 25mmx3/4", 32mmx3/4", 32mmx1"; 40mm x 1 1/4", 50mmx 1 1/2", 63mmx2", 75mmx 2 1/2"; 90mmx3"
Male Elbow QX92 16mmx1/2"; 20mmx 1/2", 25mmx1/2", 25mmx3/4", 32mmx3/4", 32mmx1"; 40mm x 1 1/4", 50mmx 1 1/2", 63mmx2", 75mmx 2 1/2"; 90mmx3"
Clamp Saddle QX93 40mmx1/2", 40mmx3/4", 40mmx1", 50mmx1/2", 50mmx3/4", 50mmx1"; 63mmx1/2", 63mmx3/4", 63mmx1"; 75mmx 3/4"; 75mmx1"; 75mmx 1 1/2"; 90mmx 1/2", 90mmx 3/4", 90mmx1", 90mmx 1 1/2", 90mmx2", 110mmx 1/2", 110mmx3/4", 110mmx1", 110mmx 1 1/2", 110mmx2", 110mmx3"

3. Installation process:

PP Female Pipe and Fittings Compression Fitting for Irrigation Made of 100% Material

4. PP Compression Fittings Packing Way and Export Photo:

PP Female Pipe and Fittings Compression Fitting for Irrigation Made of 100% Material PP Female Pipe and Fittings Compression Fitting for Irrigation Made of 100% Material PP Female Pipe and Fittings Compression Fitting for Irrigation Made of 100% Material

5. Applications:

Irrigation
water supply
Garden
cold water supply
Industry

PP Female Pipe and Fittings Compression Fitting for Irrigation Made of 100% Material PP Female Pipe and Fittings Compression Fitting for Irrigation Made of 100% Material
6. Showroom display:

PP Female Pipe and Fittings Compression Fitting for Irrigation Made of 100% Material
7. Certificate:

PP Female Pipe and Fittings Compression Fitting for Irrigation Made of 100% Material
8. Our Factory View

Our factory covers an area of 20,000 square meters and has fixed assets of 50 million RMB. Our factory has more than 100 employees. It has a mold department, a piping system department, a raw material mixing system, a pelletizing production line, and a pipe extrusion production line. There are 50 injection molding machines with an annual production capacity of 8,000 tons.

PP Female Pipe and Fittings Compression Fitting for Irrigation Made of 100% Material
9. Company Profile

Hi, I'm Emy Zhao. I'm the founder of Ningbo Qianxiang Huiya International Trade Co., Ltd.

Just like Silicon Valley garage startups, I started NB-QXHY in my small plant in 2008. From our humble beginnings and throughout, we have strived to innovate and deliver quality plastic valve/pipe fittings. I am proud to say that we have continued to see fairly large growth within our company; as a result we have expanded our product lines, facilities, personnel, machinery and technology to better serve our customers.

NB-QXHY as a manufacturer has been designed to listen to the needs of the distributor and recognize voids in the industry, and then react quickly with new product development, extended product assurance, and superior service. We feel this is a different between any other company at this time.

Thank you for entrusting us with your business. We are deeply committed to being your most dependable supplier. If you have any questions, please let me know.

PP Female Pipe and Fittings Compression Fitting for Irrigation Made of 100% Material
10. FAQ

Our Advantages:

(1) High pressure can stand: PN10, PN16, PN35, PN40; 150psi, 235psi etc, as customers' request;

(2) Well and high quality control, within 1% leakage;

(3) Environment friendly, non-toxic, good looking and long service life;

(4) Light weight, easy to handle and transport;

(5) Soft colors and excellent design, suitable for installation either exposed or hidden;

(6) Wonderful ability in chemical corrosion resistance;

(7) Easy and fast installation, making cost minimized;

(8) Widely used in building, irrigation, industry and swimming pool;

(9) Small order acceptable;

(10) Customer's design and logo are welcome.

Why Us?

(1) We provide OEM service and submit Various styles, latest designs to our clients;

(2) We work with big customers in Southeast Asia, Africa, Middle East, North America, South America;

(3) According to the needs of customers in different regions, we match different quality and thickness valves with various styles, so that our customers are very competitive in the market!

(4) Our high quality PVC valve can be consistent with European and American national brand valves!

(5) We have great experience on providing high quality products and most professional service to clients about 10 years more!

(6) Customers choose our products, can mix and match our PVC pipe fittings, PVC butterfly valves, PP Fittings, irrigation products to buy together, so that the customer product line is more abundant, both quality and delivery time are guaranteed.

(7) We can flexible from China any port export! Welcome you inquiry us!
