Lock Seam Roof Panel Roll Forming Machine 7.5KW PPGI Material
Lock Seam Roof Panel Roll Forming Machine 7.5KW PPGI Material
Lock Seam Roof Panel Roll Forming Machine 7.5KW PPGI Material
Lock Seam Roof Panel Roll Forming Machine 7.5KW PPGI Material
Lock Seam Roof Panel Roll Forming Machine 7.5KW PPGI Material
Lock Seam Roof Panel Roll Forming Machine 7.5KW PPGI Material
Lock Seam Roof Panel Roll Forming Machine 7.5KW PPGI Material
Lock Seam Roof Panel Roll Forming Machine 7.5KW PPGI Material
Specifications
Brand Name :
FUMING
Model Number :
YX73-480
Certification :
CE,SGS, CSA, UL
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T, L/C
Delivery Time :
45 working days
Packaging Details :
roll forming machine without outer packing, shipped by container
Transmission :
Gear/sprocket
Roller Material :
45# Steel, hard chrome coated
Material :
PPGI
Power :
7.5KW
Control System :
PLC Control
Forming Speed :
18-20m/min
Cutting Type :
Hydraulic Cutting
Description

Lock Seam Roll Forming Machine for YX73-480 Profile

Product Description:

The Lock Seam Roll Forming Machine is designed to meet the high performance requirements. It adopts the PLC control system, transmission with gear/sprocket, and has a high precision cutting length. The Lock Seam Roll Forming Machine is ideal for producing roof panels with high accuracy, high efficiency and stable performance. With a wide range of applications, it is an ideal choice for roof panel forming operation. Its advanced technology ensures a reliable, efficient and safe operation in various environments.

Features:

  • Product Name: The Lock Seam Roll Forming Machine for YX73-480 Roof Profile
  • Roller Station: 14 Stations
  • Material: PPGI
  • Transmission: Gear/sprocket
  • Forming Speed: 18-20m/min
  • Drive Type: Motor Driving
  • The Lock Seam Roll Forming Machine

Drawing:

Lock Seam Roof Panel Roll Forming Machine 7.5KW PPGI Material

Technical Parameters:

ROLL FORMING MACHINE FOR YX73-480 LOCKSEAM PROFILE
Material Specification
Thickness 0.3mm to 0.8mm
Effective width 470mm
Feeding width Approx.600mm
Material PPGI, GI
Yield strength 550MPa
Machine Components
5Ton*1250mm Simple Decoiler
Load capacity Max.5Tons
Coil Inner diameter 508±30mm
Coil outer diameter Max.1300mm
Coil width Max.1250mm
Roll Forming Machine
Driving system Gear/sprocket
Forming station 14 stations
Roller material 45# steel, CNC lathes, hard chrome coated
Shafts Diameter Φ75mm
Main motor 7.5KW, frequency speed control
Line speed of rollformer Approx. 18 to 20m/min
Hydraulic Cutting Device
Cutting type Slug breaker
Cutting tool material Cr12, heat treatment
Hydraulci pump motor 4KW
PLC Control System
Function Control quantity and cutting length automatically
PLC Siemens
Touch screen Siemens
Inverter Schneider or Delta
Encoder Omron
Cut-to-length tolerance ≤±2 mm
Control Voltage 24V
Product Rack Un-powered, three units
Electrical Seamer 1 unit
Hand Seamer 2 units

Lock Seam Roof Panel Roll Forming Machine 7.5KW PPGI MaterialLock Seam Roof Panel Roll Forming Machine 7.5KW PPGI MaterialLock Seam Roof Panel Roll Forming Machine 7.5KW PPGI MaterialLock Seam Roof Panel Roll Forming Machine 7.5KW PPGI MaterialLock Seam Roof Panel Roll Forming Machine 7.5KW PPGI MaterialLock Seam Roof Panel Roll Forming Machine 7.5KW PPGI MaterialLock Seam Roof Panel Roll Forming Machine 7.5KW PPGI MaterialLock Seam Roof Panel Roll Forming Machine 7.5KW PPGI Material

Applications:

XIAMEN FUMING Lock Seam Roll Forming Machine, model number YX73-480, is a reliable and cost-effective equipment. The voltage of the equipment can be customized.

Support and Services:

Lock Seam Roll Forming Machine Technical Support and Services

We provide comprehensive support for Lock Seam Roll Forming Machines, including:

  • Remote technical support
  • On-site maintenance and repair services
  • Training and consultation to ensure optimal operation
  • Warranty service

Our team of experienced professionals will work with you to ensure your Lock Seam Roll Forming Machine is running efficiently and reliably.

If you have any questions or require support for your Roll Forming Machine, please contact us.

FAQ:

Q 1: How can customers be assured that XIAMEN FUMING will deliver qualified roll forming machines?

A 1: Customers can send their technician or entrust a third party to XIAMEN FUMING’s factory to do machine inspection before delivery.

XIAMEN FUMING can send their engineers to the buyer’s factory for machine installation and commissioning.

Our roll forming machine is guaranteed for one year in correct operation and maintenance.

Q 2: How does the customer install the machine when it arrives?

A 2: Our engineers will go to your factory for machine installation and commissioning once you get your machine ready(including electricity, testing material, hydraulic oil, auxiliary staff, transport and lifting device, etc.), they will instruct your technician how to operate the machine. Online supports including video call will be provided if our engineers cannot visit your place because of pandemic.

Q 3: Does XIAMEN FUMING provide customized roll forming machines?

A 3: Yes, we design and make roll forming machines according to the latest market trend and the specific requirements suggested by customers.
