High Precision Laser Radar Meter Explosion Proof Measuring Equipment
High Precision Laser Radar Meter Explosion Proof Measuring Equipment
Specifications
Brand Name :
NUOYINGJIAYE
Model Number :
NYTOFUL
Certification :
CE
Place of Origin :
Xi'an, Shaanxi,China
MOQ :
1
Price :
Please Contact Me
Payment Terms :
T/T
Supply Ability :
1000 pcs/ pre month
Delivery Time :
7-15 working days
Packaging Details :
carton, 40cm×30cm×30cm
Product model :
NYTOFUL
Wave length :
635~650nm
Laser class :
Class II
Power supply :
24VDC
Signal output :
4…20mA/RS485
Process connection :
Thread、flange (optional)
Electrical Interface :
M20×1.5，½"NPT
Protection class :
IP65, IP67, IP68
Description

Laser Radar Meter High Precision Widely Range Explosion Grade

Laser Radar Meter Discription

NYTOFUL Lidar level meter is a new type of distance measuring equipment independently developed by the company. It has the advantages of high accuracy, fast response, large range and non-contact measurement. It is suitable for gas tank cabinet detection, piston balance and gas tank piston tilt detection occasion. The product has been inspected and approved by the National Instrument Safety Supervision and Inspection Station, and conforms to national standards. The explosion-proof mark is ExdIIBT4/ExdIICT6 GB. Users can choose this product to be used in corresponding explosive hazardous places according to regulations.

Laser Radar Meter Design Feature

◎Long distance, high precision: Range can be set freely, ranging accuracy ±1mm, range (0.001-150m).

◎Simple operation mode: Continuous measurement, measurement interval can be set.

◎Digital output and analog output: It has RS485 standard MODBUS protocol, 4-20mA output, and two groups of programmable switching output.

◎Protection grade: IP 67(against dust and moisture).

Laser Radar Meter Technical Parameter

Typical application Gas tank position test, piston balance test, etc
Product model NYTOFUL
Laser class Class II
Wavelength 635~650nm
Power supply 24VDC
Signal output 4…20mA/RS485
Measurement accuracy ±1mm
Laser transmit power <1mW
Process connection Thread,flange (optional)
Process temperature -30 ~ + 70℃;-30 ~ + 80℃
Electrical Interface M20×1.5,½"NPT
Protection class IP65, IP67, IP68

※Note:The product can be customized according to the specific requirements of users.
