Parabolic Antenna Radar Level Gauge For Tank Height Measurement
Parabolic Antenna Radar Level Gauge For Tank Height Measurement
Parabolic Antenna Radar Level Gauge For Tank Height Measurement
Parabolic Antenna Radar Level Gauge For Tank Height Measurement
Specifications
Brand Name :
NUOYINGJIAYE
Model Number :
NYRD-810
Certification :
Explosion-proof certificate
Place of Origin :
China
MOQ :
1
Price :
$400 to $1800
Payment Terms :
T/T
Supply Ability :
500 pcs/ pre month
Delivery Time :
7 work days
Packaging Details :
60cm×30cm×30cm
Measuring range :
80m
Case material :
cast aluminum case
Antenna material :
304 316L
Process connection :
universal flange, clamp and bracket are optional
Echo sampling :
100 times/s
Operating temperature :
-40~80℃
Signal output :
4...20mA/HART/RS485/Modbus...
Power :
3W
Description

26GHz NYRD-810 Radar Level Meter

The NYRD-810 parabolic antenna radar level gauge is used for the height measurement of the tank material level.The antenna of the high-frequency radar level gauge emits extremely narrow microwave pulses. This pulse propagates in space at the speed of light and meets the surface of the measured medium. Part of its energy is reflected back and received by the same antenna.
The time interval between the transmitted pulse and the received pulse is proportional to the distance from the antenna to the surface of the measured medium. Due to the extremely high propagation speed of electromagnetic waves, the time interval between the transmitted pulse and the received pulse is very small (nanosecond order) and difficult to confirm. The 26G high-frequency radar level meter uses a special related solution technology that can accurately identify the time interval between the transmitted pulse and the received pulse, so as to further calculate the distance from the antenna to the surface of the measured medium.

Radar Level Meter Technical Parameter

Typical application Monitoring Solids, dust, particles, etc
Transmit frequency 26GHz
Accuracy 3mm
Range 80m
Antenna material 304 316L (optional)
Echo sampling 100 times/s
Process temperature -40~130℃
Ambient humidity 0~90%
Resolution 1mm
Process connection Flange or bracket installation
Electrical Interface M20×1. 5, ½ " NPT
Signal output 4...20mA/HART/RS485/Modbus...
Supply power 24V DC (optional)
Power 3W
Explosion-proof grade ExiaⅡCT6(optional)
Protection class IP67

※ Note: Products can be customized according to the specific requirements of users!
