RS485 High Accurate Magnetostrictive Level Gauge 220VAC Magnetostrictive Level Transmitter
RS485 High Accurate Magnetostrictive Level Gauge 220VAC Magnetostrictive Level Transmitter
RS485 High Accurate Magnetostrictive Level Gauge 220VAC Magnetostrictive Level Transmitter
RS485 High Accurate Magnetostrictive Level Gauge 220VAC Magnetostrictive Level Transmitter
RS485 High Accurate Magnetostrictive Level Gauge 220VAC Magnetostrictive Level Transmitter
RS485 High Accurate Magnetostrictive Level Gauge 220VAC Magnetostrictive Level Transmitter
RS485 High Accurate Magnetostrictive Level Gauge 220VAC Magnetostrictive Level Transmitter
RS485 High Accurate Magnetostrictive Level Gauge 220VAC Magnetostrictive Level Transmitter
RS485 High Accurate Magnetostrictive Level Gauge 220VAC Magnetostrictive Level Transmitter
RS485 High Accurate Magnetostrictive Level Gauge 220VAC Magnetostrictive Level Transmitter
Specifications
Brand Name :
NUOYINGJIAYE
Model Number :
NYCZ
Certification :
Explosion-proof certificate
Place of Origin :
China
MOQ :
1
Price :
$240 to $1900
Payment Terms :
T/T
Supply Ability :
300 pcs/ pre month
Delivery Time :
7 work days
Packaging Details :
Export standard packing
Measuring range :
0~25m
Power supply :
24VDC，220VAC
Material :
304，316L(optional)
Accuracy :
Analog: 0.3% RS485: 0.1%
Protection grade :
Display instrument IP67, IP67
Operating temperature :
-40~130℃
Signal output :
Analog: 4-20mA Digital: RS485
Bottom Non detection zone :
50mm (customizable)
Description

Magnetostrictive Liquid Level Gauge

  • None contact continuously measurement, wear-proof permanently.
  • No drift and do not need calibration.
  • Absolute position measurement, resolution could reach to 0.15mm
  • Could detect multi liquids, interfaces or liquid levels at same time
  • Value range of measurement could be set by users.

RS485 High Accurate Magnetostrictive Level Gauge 220VAC Magnetostrictive Level Transmitter

Magnetostrictive Liquid Level Meter Technical Parameter

Applications liquid level
Measurement range

Probe: 0-50~6000mm Cable: 25m
Accuracy ±0.5mm
Power supply 24VDC ±10%
Signal output 4~20mA / Hart / RS485
Working current 4~20mA; 20.4mA
Load characteristics when current output, maximum load resistance 600 Q voltage output, maximum load Resistance 2mA
Process temperature -40〜130 °C,-40〜250 °C
Ambient temperature -40〜80°C
Temperature effect ±0.5 °C
Process pressure - 0.1 ~ 4.0MPa
Resolution ±lmm
Response time 0.2 ms
Rod material 304/316L (optional)
Process connection Thread, flange, Support mounting (optional)
Site display LCD (optional)
Housing material stainless steel / aluminum (optional)
Protection grade IP67
Explosion proof grade Exia IICT6 (optional)


※ Note: Products can be customized according to the specific requirements of users!
