LCD Display 4-20mA Temperature Transmitter Sensor 24VDC Explosion Proof
LCD Display 4-20mA Temperature Transmitter Sensor 24VDC Explosion Proof
LCD Display 4-20mA Temperature Transmitter Sensor 24VDC Explosion Proof
LCD Display 4-20mA Temperature Transmitter Sensor 24VDC Explosion Proof
LCD Display 4-20mA Temperature Transmitter Sensor 24VDC Explosion Proof
LCD Display 4-20mA Temperature Transmitter Sensor 24VDC Explosion Proof
LCD Display 4-20mA Temperature Transmitter Sensor 24VDC Explosion Proof
LCD Display 4-20mA Temperature Transmitter Sensor 24VDC Explosion Proof
Specifications
Brand Name :
NUOYINGJIAYE
Model Number :
NT-93420-II
Certification :
Explosion-proof certificate,SIL3
Place of Origin :
Xi'an,China
MOQ :
1pc
Price :
$85.0~$280.0
Payment Terms :
T/T
Supply Ability :
500pcs/pre month
Packaging Details :
40*30*30cm Carton
Measuring Range :
-200-500 ℃,0~1000℃,0~1300℃,0~1600℃
Power Supply :
24VDC
Accuracy :
0.5 ℃, 0.2 ℃, 0.1 ℃ (interval setting)
Protection Grade :
IP65
Stand-by Power Consumption :
<0.02mA
Working Environment :
Temperature - 20 °C ~ 60°C; humidity <9 0%
Display :
LCD
Output :
4-20mA、RS485
Description

High Accuracy LCD Display 4-20mA Temperature Transmitter

High Accuracy LCD Display 4-20mA Temperature Transmitter Description:

High AccuracyTemperature Transmitter with LCD and hart 4-20ma output is a high performance device that receives thermocouple/RTD/ohm/mA input and output mA with hart communication protocol .Three internal keys to set parameter . Zero span calibration can be achieved either by hart or keypad.

High Accuracy LCD Display 4-20mA Temperature Transmitter Technical Parameters:

Item High Accuracy LCD Display 4-20mA Temperature Transmitter
Measuring Range -200-500 ℃,0~1000℃,0~1300℃,0~1600℃
Accuracy 0.2 ℃, 0.1 ℃
Display LCD/LED
Power Supply 24V
Stand-by Power Consumption <0.02mA
Working Environment Temperature - 20 °C ~ 60°C; humidity <9 0%
Explosive-proof Grade ExdIICT6(optional)
Process Interface M27×2; M20*1.5 ; flange
Probe Material Stainless steel 304, 316, 316L, GH3030,GH3039,Sic-Si ceramics,SiC ceramics etc.

High Accuracy LCD Display 4-20mA Temperature Transmitter Features:

1.Aluminum alloy case
2.Imported temperature sensor, high anti-interference
3.Saving cost of compensating lead wire and installation
4.Wide range of -200℃-1600℃.
5.Cold junction compensation and nonlinearity correcting circuit

6.Simple structure, easy to manufacture

7.Easy installation, low cost

8. Small inertia

9.Measure temperature by electrical signal, meet the request for remote measurement and control

10. Suitable for different measure request (special site or narrow spot),such as temperature measurement at point or face.

High Accuracy LCD Display 4-20mA Temperature Transmitter Details:

LCD Display 4-20mA Temperature Transmitter Sensor 24VDC Explosion Proof

LCD Display 4-20mA Temperature Transmitter Sensor 24VDC Explosion ProofLCD Display 4-20mA Temperature Transmitter Sensor 24VDC Explosion Proof
